10m 12m 15m Tapered Power Telescopic Steel Pole Electrical Equipment Suppliers

Certification
China Jiangsu milky way steel poles co.,ltd certifications
China Jiangsu milky way steel poles co.,ltd certifications
Dear Sirs, Hereby we confirm that JiangSu MilkyWay steel poles co., ltd is our partner for several years. Since that time this company has shown itself as reliable supplier of qualitative products.We also would like to note that they provide top level service and all kinds of support.We plan to continue our fruitful cooperation co-operation for many years more.

—— Abacus

We do hereby certify the 69 KV transmmision line steel pole(from 25ft to 90 ft ) manufacuterd by Jiangsu Milky Way Steel Poles Co., Ltd since 2010.We are satisfied with their quality,service and the ways and attention they showed toward our order.

—— National Electricity Company

I'm Online Chat Now

10m 12m 15m Tapered Power Telescopic Steel Pole Electrical Equipment Suppliers

China 10m 12m 15m Tapered Power Telescopic Steel Pole Electrical Equipment Suppliers supplier
10m 12m 15m Tapered Power Telescopic Steel Pole Electrical Equipment Suppliers supplier 10m 12m 15m Tapered Power Telescopic Steel Pole Electrical Equipment Suppliers supplier 10m 12m 15m Tapered Power Telescopic Steel Pole Electrical Equipment Suppliers supplier 10m 12m 15m Tapered Power Telescopic Steel Pole Electrical Equipment Suppliers supplier 10m 12m 15m Tapered Power Telescopic Steel Pole Electrical Equipment Suppliers supplier

Large Image :  10m 12m 15m Tapered Power Telescopic Steel Pole Electrical Equipment Suppliers

Product Details:

Place of Origin: China
Brand Name: MilkyWay
Certification: ISO9001/BV/SGS
Model Number: Steel Power Pole

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T, L/C at sight
Supply Ability: 300pcs per day
Contact Now
Detailed Product Description
Product Name: Steel Power Pole Application: Power Distribution
Material: Gr65 Minimum Yield Strength: 460 Mpa
Max Ultimate Tensile Strength: 620 Mpa Wall Thickness: 1mm-36mm
High Light:

electric utility poles

,

steel utility poles

 10m 12m 15m Tapered Power Electrical Equipment Suppliers Telescopic Steel Pole





Specifications:

Types

Length

45ft 50ft 55ft 60ft 65ft 70ft
13.75m 15.25m 16.80m 18.30m 19.85m 21.35m
B ( 0°-2°)
Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 345 370 395 415 435 455
Thickness (mm) 6 6 6 6 6 6
E ( 2°-15°)
Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 545 585 625 660 700 740
Thickness (mm) 6 6 6 6 6 6
C ( 15°-30°)
Top diameter (mm) 250 250 250 250 250 250
Butt diameter (mm) 600 645 690 730 770 805
Thickness (mm) 6 6 6 6 6 6
D ( 30°-90°)
Top diameter (mm) 300 300 300 300 300 300
Butt diameter (mm) 680 730 725 765 755 790
Thickness (mm) 6 6 7 7 8 8
HS ( 0°-2°)
Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 340 360 385 400 420 440
Thickness (mm) 6 6 6 6 6 6
HT ( 2°-15°)
Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 485 520 550 580 615 645
Thickness (mm) 6 6 6 6 6 6
3T ( 15°-30°)
Top diameter (mm) 250 250 250 250 250 250
Butt diameter (mm) 520 540 565 595 615 640
Thickness (mm) 6 6 6 6 6 6
3D ( 30°-90°)
Top diameter (mm) 300 300 300 300 300 300
Butt diameter (mm) 585 620 650 680 715 765
Thickness (mm) 6 6 6 6 6 6





 Descripition of material:
 1. Poles are made by the high-quality metal plants,which were molded into the multi-row cone-shaped  vertical steel barwith hot galvanized anti-corrosion treatment
 2. Light plate frame is made by high-quality stainless steel
 3. Fastened bolts and nuts of stainless steel

 10m 12m 15m Tapered Power Telescopic Steel Pole Electrical Equipment Suppliers 0





 Our Service:

 1. Reply your inquiry in 24 working hours.

 2. Experienced staffs answer all your questions in fluent English.

 3. Customized design is available. UEM&UBM are welcomed.

 4. Exclusive and unique solution can be provided to our customer by our well-trained and professional  engineers and  staff.

 5. Special discount and protection of sales are provided to our distributor.

 6. Professional factory : We are manufacturer, specializing in producing all kinds of steel poles for more  than 20 years,  competitive with good quantity.

 7 Sample: We can send out sample for test in one week if the order quantity is big enough. But the  shipment charges is  sually paid by your side, the charges will be rebounded when we have formal order.

 8. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to  ensure our  products to be finished in high quality and stable feature. Welcome to contact us or visit our  company.

 10m 12m 15m Tapered Power Telescopic Steel Pole Electrical Equipment Suppliers 1






 Company Introduction:
 Jiangsu Milky Way Steel Poles which established on 1991 is located in Wuxi,East of China ,near one of  the largest sea port of China ,Shanghai,Port .
 Our Company has 24 years experience on producing the steel poles including the transmission power  pole,street light pole,high mast pole and so on.
 We exported to oversea countries since 1991 and our products have been delivered to more than 70  countries and areas ,including America,Australia ,Russia ,Germany ,Span,Philippines ,Malaysia,Africa  and so on.
 We are the supplier of many big project in many countries,like the street light pole of Dubai Tower.the  high mast pole for Sochi Winter Olympic Game and so on.

 10m 12m 15m Tapered Power Telescopic Steel Pole Electrical Equipment Suppliers 2
