14m 1000Dan Utility Power Poles For African Distribution Line

Large Image : 14m 1000Dan Utility Power Poles For African Distribution Line

Product Details:

Place of Origin:	China
Brand Name:	Milky Way
Certification:	ISO, BV,
Model Number:	14m 1000Dan Utility Power Poles For African Distribution Line

Payment & Shipping Terms:

Minimum Order Quantity:	one 40 HQ
Price:	negotiation
Packaging Details:	as per customer request
Delivery Time:	usually 2 weeks after confirming
Payment Terms:	T/T
Supply Ability:	300 pieces pole per day

Contact Now

Detailed Product Description

Surface Treatment:	Hot Dip Galvanized	Type:	Straight Pole, Tensile Pole, Turn Pole
Thickness:	1mm To 30mm	Power:	10kv~550kv
Suit For:	Electricity Distribution	Length Of Per Section:	Within 14m Once Forming Without Slip Joint
High Light:	electrical transmission poles , high voltage pole

14m 1000Dan Utility Power Poles For African Distribution Line

Specification

Material	Usually Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield strength>=235n/mm2 As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52-
Safety Factor	Safety factor for conducting wine : 8 Safety factor for grounding wine : 8
Design Load in Kg	300~ 1000 Kg appliced to 50cm from the to pole
Marks	Nane palte through rivert or glue ,engrave ,emboss as per customer requirement
Joint of Poles	Insert mode,innerflange mode,face to face joint mode .
Minimum yield strength	355 mpa
Minimum ultimate tensile strength	490 mpa
Max ultimate tensile strength	620 mpa
Length of per section	Within 14m once forming without slip joint
Welding	We has past flaw testing.Internal and external double welding makes the welding beautiful in shape Welding Standard :AWS ( American Welding Society ) D 1.1
Production Process	Rew material test → Cuttingj →Molding or bending →Welidng (longitudinal ) →Dimension verify →Flange welding →Hole drilling →Calibration → Deburr →Galvanization or powder coating ,painting →Recalibration → Thread →Packages
Packages	Our poles as normal cover by Mat or straw bale at the top and bottom , anyway also can following by client required , each 40HC or OT can loading how many pcs will calculation base on the client actually specification and data.

14m 1000Dan Utility Power Poles For African Distribution Line 0

Package Type:
Our poles as normal cover by Mat or straw bale at the top and bottom ,anyway also can following by client required , each 40HC or OT can loading how many pics will calculation base on the client actually specification and data.

14m 1000Dan Utility Power Poles For African Distribution Line 1

Easy work: more than 23 years pole field. quickly understand your meaning and let you get your result.
Lowest MOQ: lowest quantity from 1Ton depends on different style .
OEM Accepted: We can produce any pole of your design.
Good Service: We treat clients as friends.
Good Quality: We have very strict quality control system .Good reputation in the market.
Fast & Cheap Express service: We have big discount from forwarder (Long-term Contract with TNT,DHL,UPS,FEDEX,EMS ).
Manufacturer Capacity : 300 pieces/day.

14m 1000Dan Utility Power Poles For African Distribution Line 2
