Product Details:
Payment & Shipping Terms:
|
| Product Name: | Steel Transmission Poles | Power: | 10 KV ~550 KV |
|---|---|---|---|
| Torlance Of The Dimenstion: | +- 2% | Flange Size: | 450mm |
| Wall Thickness: | 3mm | Warranty: | 15 Years |
| High Light: | floodlight pole,commercial light poles |
||
Galvanized Gr65 25m 3000dan Steel Power Pole With 4.5mm Wall Thickness
Descripition of material:
1. Poles are made by the high-quality metal plants,which were molded into the multi-row cone-shaped vertical steel barwith hot galvanized anti-corrosion treatment
2. Light plate frame is made by high-quality stainless steel
3. Fastened bolts and nuts of stainless steel
| Steel Material Grade | ||||||
| China GB | America ASTM ASME | Japan JIS | Europen EN |
Gemany DIN |
England BS |
International ISO |
| 16Mn 14MnNd Q345(A.B.C.D.E) |
A572MGr.50 A633MGr.C A633MGr.D |
SM490A SM490B SM490C |
S355JR S355JOS 355J2G3 S355J2G 4S355K2 G3 S355K2G 4S355N S355NL |
St52-3 | 50A 50B 50C 50D 50DD |
E355DD E355E Fe510B Fe510D |
| WH60/Q460 ( C.D.E) |
A572MGr.65 | SM570 | S460N S460NL |
StE460 | 55C 55E |
E460C E460D |
| Q235 ( A.B.C.D) Q275 20 25 30 35 40 45 50 55 50Mn |
A283MGr.C A283MGr.D 1020 1025 1030 1035 1040 1045 1050 1055 1053 |
SS400 SM400( A B) SS490 S20CS22C S25C S28C S30C S33C S35C S38C S40C S43C S45C S48C S50C S53C S55C S58C SWRH52B |
S235JR S235JO S235J2G 3 1C22 1C25 1C30 1C35 1C40 1C45 1C50 1C55 2C50 |
St37-2 St37-3 1C22 1C25 1C30 1C35 1C40 1C45 1C50 1C55 2C50 |
40A 40B 40C 40D 1C22 1C25 1C30 1C35 1C40 1C45 1C50 1C55 2C50 |
Fe360 ( A.B.C.D) Fe430A C25E4 C30E4 C35E4 C40E4 C45E4 C50E4 C55E4 SL, SM |
Welding
We have past flaw testing. Internal and external double welding makes the welding beautiful in shape
Welding Standard :AWS ( American Welding Society ) D 1.1
Production Process
Raw material test → Cutting →bending →Welding (longitudinal )→Dimension verify →Flange welding →Hole drilling →sample assemble → surface clean→ Galvanization or powder coating ,painting →Recalibration →Packages
Surface Treatment
Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
Description:
Standard Accessory
-Top plate
-Base plate
-Bottom strip
-Standard hole
-Climbing rung
-Anchor bolt
-Bitumen protection
-Painted marking
-Removable ladder
These are the standard accessories of the electric pole.
Specification:
| Overseas Project For Electric Pole | ||||
| Country | Utility Name | Voltage Level | Type | Year of supply |
| Philippines | NEA,NGCP | 69KV | 25FT-100FT,According to customer requirement | Every Month |
| Costa Rica | Electric Pole | 10M,11M | Every Month | |
| Congo | Electric Pole | 8M,10M | Every Month | |
| Ghana | Ghana Elercity Company | 11m,12m | 2016 | |
| Ghana | Ghana Elercity Company | 10m,11m | 2015 | |
| Pakistan | Wapda | 132kv | SPA,SPD,SPG | 2013 |
| Saudi Arabic | Saudi Electricity Company | 10m electric pole | 2011 | |
| Ecuador | Celec | 138kv | PP-B40 | 2009 |
| More project,please visit our website or contact with our sales to get more information. | ||||
Quality Control
We strictly follow the standard of ISO9001-2008. Quality is in the first place at every stage of production to ensure the product compliance to the specification/standards. Careful inspections are carried out by highly trained inspection engineers during every procedure from raw material stage to finished product and delivery.
