30 Ft 3mm NEA Galvanized Steel Power Pole For Overhead Line Project

China 30 Ft 3mm NEA Galvanized Steel Power Pole For Overhead Line Project supplier
30 Ft 3mm NEA Galvanized Steel Power Pole For Overhead Line Project supplier 30 Ft 3mm NEA Galvanized Steel Power Pole For Overhead Line Project supplier 30 Ft 3mm NEA Galvanized Steel Power Pole For Overhead Line Project supplier 30 Ft 3mm NEA Galvanized Steel Power Pole For Overhead Line Project supplier

Large Image :  30 Ft 3mm NEA Galvanized Steel Power Pole For Overhead Line Project

Product Details:

Place of Origin: China
Brand Name: Milky Way
Certification: ISO/SGS/BV
Model Number: 30ft 3mm NEA galvanized electrical power pole for overheadline project

Payment & Shipping Terms:

Minimum Order Quantity: one 40HQ
Price: negotiation
Packaging Details: as per customer request
Delivery Time: usually 2 weeks after confirming
Payment Terms: T/T
Supply Ability: 300 pieces pole per day
Contact Now
Detailed Product Description
Thickness: 1mm To 30mm Shape: Conoid, Multi-pyramidal,Columniform, Polygonal Or Conical
Power: 10kv~550kv Suit For: Electricity Distribution
Wind Speed: 160km/h, 30m/s Welding Standard: AWS D 1.1
High Light:

nea galvanized steel power pole

,

3MM galvanized steel power pole

,

30 ft galvanized steel power pole

30ft 3mm NEA galvanized electrical power pole for overheadline project



Mechanical Property



The metal supports are designed to withstand the nominal force F and the pressure of the wind V applied at 0.25m from the top. Under these loads, the safety factor with respect to the elastic limit of the steel is larger than 1.8. The post also resists a torque equal to (F+V) ×1m. Tests shows the load intervened when breaking is around 2 times of design load.









Galvanization



Standard: NFA91121

Average thickness of the galvanization: Not less than 70



30 Ft 3mm NEA Galvanized Steel Power Pole For Overhead Line Project 0



Manufacturer Tolerance



- Component Length: -25mm to 75mm

- Straightness: 2mm/m

- Twisting degree: 1̊ per 3 meters length

- Ovalisation : Maximum is 3%

- The average diameter : +/-0.5%

-Slip length: +/-150mm





Standard Accessory



- Top plate

- Base plate

- Bottom Strip

- Standard Hole

- Climbing Rung

- Anchor bolt

- Bitumen Protection
- Painted Marking

- Removable Ladder



30 Ft 3mm NEA Galvanized Steel Power Pole For Overhead Line Project 1



The information to inquiry or purchase



- Steel pole height and force

- Cross arm type and length, the position to install in the steel pole

- The method to fix the cross arm (use Bolt to connect or use one or two   template to weld in the steel pole to install the cross arm)

- Safety factor of the steel pole

- Wind speed

- Type of climbing rung

- Destination port

- Others



30 Ft 3mm NEA Galvanized Steel Power Pole For Overhead Line Project 2
