70FT 90FT Transimission Line Steel Power Pole Gi Octagonal Pole With Bitumen

Certification
China Jiangsu milky way steel poles co.,ltd certification
China Jiangsu milky way steel poles co.,ltd certification
Dear Sirs, Hereby we confirm that JiangSu MilkyWay steel poles co., ltd is our partner for several years. Since that time this company has shown itself as reliable supplier of qualitative products.We also would like to note that they provide top level service and all kinds of support.We plan to continue our fruitful cooperation co-operation for many years more.

—— Abacus

We do hereby certify the 69 KV transmmision line steel pole(from 25ft to 90 ft ) manufacuterd by Jiangsu Milky Way Steel Poles Co., Ltd since 2010.We are satisfied with their quality,service and the ways and attention they showed toward our order.

—— National Electricity Company

I'm Online Chat Now

70FT 90FT Transimission Line Steel Power Pole Gi Octagonal Pole With Bitumen

China 70FT 90FT Transimission Line Steel Power Pole Gi Octagonal Pole With Bitumen supplier
70FT 90FT Transimission Line Steel Power Pole Gi Octagonal Pole With Bitumen supplier 70FT 90FT Transimission Line Steel Power Pole Gi Octagonal Pole With Bitumen supplier 70FT 90FT Transimission Line Steel Power Pole Gi Octagonal Pole With Bitumen supplier 70FT 90FT Transimission Line Steel Power Pole Gi Octagonal Pole With Bitumen supplier 70FT 90FT Transimission Line Steel Power Pole Gi Octagonal Pole With Bitumen supplier

Large Image :  70FT 90FT Transimission Line Steel Power Pole Gi Octagonal Pole With Bitumen

Product Details:

Place of Origin: China
Brand Name: MilkyWay
Certification: ISO9001/BV/SGS
Model Number: Steel Power Pole

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T, L/C at sight
Supply Ability: 300pcs per day
Contact Now
Detailed Product Description
Product Name: Steel Power Pole Application: Power Distribution
Material: Gr65 Minimum Yield Strength: 460 Mpa
Max Ultimate Tensile Strength: 620 Mpa Wall Thickness: 1mm-36mm
High Light:

electric utility poles

,

steel utility poles


Yield Strength 460MPA 4mm Electric Galvanized Steel Pole with Bitumen


Specifications:

Types
Length

45ft50ft55ft60ft65ft70ft
13.75m15.25m16.80m18.30m19.85m21.35m
B ( 0°-2°)
Top diameter (mm)200200200200200200
Butt diameter (mm)345370395415435455
Thickness (mm)666666
E ( 2°-15°)
Top diameter (mm)200200200200200200
Butt diameter (mm)545585625660700740
Thickness (mm)666666
C ( 15°-30°)
Top diameter (mm)250250250250250250
Butt diameter (mm)600645690730770805
Thickness (mm)666666
D ( 30°-90°)
Top diameter (mm)300300300300300300
Butt diameter (mm)680730725765755790
Thickness (mm)667788
HS ( 0°-2°)
Top diameter (mm)200200200200200200
Butt diameter (mm)340360385400420440
Thickness (mm)666666
HT ( 2°-15°)
Top diameter (mm)200200200200200200
Butt diameter (mm)485520550580615645
Thickness (mm)666666
3T ( 15°-30°)
Top diameter (mm)250250250250250250
Butt diameter (mm)520540565595615640
Thickness (mm)666666
3D ( 30°-90°)
Top diameter (mm)300300300300300300
Butt diameter (mm)585620650680715765
Thickness (mm)666666



 Descripition of material:
 1. Poles are made by the high-quality metal plants,which were molded into the multi-row cone-shaped  vertical steel barwith hot galvanized anti-corrosion treatment
 2. Light plate frame is made by high-quality stainless steel
 3. Fastened bolts and nuts of stainless steel
 70FT 90FT Transimission Line Steel Power Pole Gi Octagonal Pole With Bitumen 0

 70FT 90FT Transimission Line Steel Power Pole Gi Octagonal Pole With Bitumen 1



 Company Introduction:
 Jiangsu Milky Way Steel Poles which established on 1991 is located in Wuxi,East of China ,near one of  the largest sea port of China ,Shanghai,Port .
 Our Company has 24 years experience on producing the steel poles including the transmission power  pole,street light pole,high mast pole and so on.
 We exported to oversea countries since 1991 and our products have been delivered to more than 70  countries and areas ,including America,Australia ,Russia ,Germany ,Span,Philippines ,Malaysia,Africa  and so on.
 We are the supplier of many big project in many countries,like the street light pole of Dubai Tower.the  high mast pole for Sochi Winter Olympic Game and so on.
 70FT 90FT Transimission Line Steel Power Pole Gi Octagonal Pole With Bitumen 2
