Double Arm 60W LED Commercial Outside Light Pole Wind - Proof High Mast Pole

Certification
Good quality Electrical Power Pole for sales
Good quality Electrical Power Pole for sales
Dear Sirs, Hereby we confirm that JiangSu MilkyWay steel poles co., ltd is our partner for several years. Since that time this company has shown itself as reliable supplier of qualitative products.We also would like to note that they provide top level service and all kinds of support.We plan to continue our fruitful cooperation co-operation for many years more.

—— Abacus

We do hereby certify the 69 KV transmmision line steel pole(from 25ft to 90 ft ) manufacuterd by Jiangsu Milky Way Steel Poles Co., Ltd since 2010.We are satisfied with their quality,service and the ways and attention they showed toward our order.

—— National Electricity Company

I'm Online Chat Now

Double Arm 60W LED Commercial Outside Light Pole Wind - Proof High Mast Pole

China Double Arm 60W LED Commercial Outside Light Pole Wind - Proof High Mast Pole supplier
Double Arm 60W LED Commercial Outside Light Pole Wind - Proof High Mast Pole supplier Double Arm 60W LED Commercial Outside Light Pole Wind - Proof High Mast Pole supplier Double Arm 60W LED Commercial Outside Light Pole Wind - Proof High Mast Pole supplier

Large Image :  Double Arm 60W LED Commercial Outside Light Pole Wind - Proof High Mast Pole

Product Details:

Place of Origin: China,Jiangsu
Brand Name: MilkyWay
Certification: ISO9001/BV/SGS
Model Number: Street Light Poles

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T, L/C at sight
Supply Ability: 300pcs per day
Contact Now
Detailed Product Description
Wind-proof: 136km/h Product Name: Double Arm 60W LED Commercial Outdoor Light Poles Wind - Proof 136km/h
Pole Finished: Galvanized High Mast Pole Payment Terms:: T/T ,L/C
Supply Ability:: 2000pcs Per Week Safty Facor: 1.8
Thickness: 3mm 4mm Customization Available Tolerance: +/-2%

Double Arm 60W LED Commercial Outdoor Light Poles Wind - proof 136km/h​









Specification:



Type

Straight Pole ,Tensile Pole ,Turn Pole

Suit for

Electricity distribution

Shape

Conoid ,Multi-pyramidal,Columniform,polygonal or conical

Material

Usually   Q345B/A572,minimum yield strength>=345n/mm2

                Q235B/A36,minimum yield strength>=235n/mm2

As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,

SS400, SS490, to ST52-

Lamp power

20 W- 400 W  (HPS/MH)

220V (+-10%) /50Hz

Torlance of the dimenstion

+- 2%

Power

10  KV ~550 KV

Safety Factor

Safety factor for conducting wine : 8

Safety factor for grounding wine : 8

Design Load in Kg

300~ 1000 Kg appliced to 50cm from the to pole

Marks

Nane palte through rivert or glue ,engrave ,emboss as per

customer requirement

Surface treatment

Hot dip galvanized Following ASTM A 123,color polyester power

or any other standard by client required.

Joint of Poles

Insert mode,innerflange mode,face to face joint mode .

Design of pole

Against earthquake of 8 grade

Wind Speed

160 Km/Hour

Minimum yield strength

355 mpa

Minimum ultimate tensile strength

490 mpa

Max ultimate tensile strength

620 mpa

Standard

ISO 9001

Length of per section

Within 14m once forming without slip joint

Welding

We has past flaw testing.Internal and external double welding

makes the welding beautiful in shape Welding Standard :AWS

( American Welding Society ) D 1.1

Thickness

1 mm to 30 mm

Production Process

Rew material test → Cuttingj →Molding or bending →Welidng

 (longitudinal )→Dimension verify→Flange welding →Hole drilling

 →Calibration → Deburr→Galvanization

or powder coating ,painting →Recalibration →Thread →Packages

Packages

Our poles as normal cover by Mat or straw bale at the top and

bottom ,anyway also can following by client required , each 40HC

or OT can loading how many pcs will calculation base on the client

actually specification and data.

Double Arm 60W LED Commercial Outside Light Pole Wind - Proof High Mast Pole





·Material :SS400, Q235,A36 (yield strength: 235Pa 24kg/mm2 Tensile Strength: 375-460Pa 38-47kg/mm2

(Other Material is Available on Request)

·Hot Dip Galvanized (≥86um)

·Any Color Polyester Powder Coated (≥100 um)

·Taper Conical , Octagonal, Polygon Section

·With demounted bracket design,easy loaded,install,and maintenance

·Theftproof slide lock

·Category: Street lighting pole, Garden Lighting pole Solar Street lighting pole, High Mast,highmast light poles,







1. Prices conditions

Price can be FOB, CIF ,EXW, or With taxes.


2. What will be the delivery time and what will be the mode of payment?
We have large quantities in Stock for normal color,Normal size ,for special color and products sizes it need to 3-5 days to customize.
50K units is available for most of our models in normal color and sizes
The payment can be T/T transaction,Letter of credit,Paypal,Western Union.


3. Shipment will be over sea or by air?
Generally speaking ,we ship the products by DHL UPS FEDEX express since the products isn’t too heavy for the transportation,
and oversea for led lights,and can be customized by your requirements.


4. Could you please send me the sample for the same. So that i could see and analyze its quality?
Yes. We can send samples first, samples need to be charged if the value is higher.


5. Will there be any contract for this business or trade?
Yes, there is a normal contract before the order is placed.
