Payment & Shipping Terms:
|Material:||Steel,GR65,With Miminum Yield Strength 460mpa||Application:||Electric Power Transmission And Distribution|
|Surface Treatment:||Hot Dip Galvanized,Hot-dip-galvanized Following ASTM123||Color:||Customer Request|
|Height:||By Client Required||Name:||Metal Power Poles|
hot dip galvanized 60 ft length 70 ft 90 ft steel pole GRADE 65 ASTM A572
|Shape||Conoid ,Multi-pyramidal,Columniform,polygonal or conical|
|Torlance of dimenstion||GR65/A572,minimum yield strength>=460n/mm2|
|Power||10 KV ~550 KV|
|Safety Factor||Safety factor for conducting wine : 8 Safety factor for grounding wine : 8|
|Design Load in Kg||300~ 1000 Kg appliced to 50cm from the to pole|
|Marks||Name palte through rivert or glue ,engrave ,emboss as per customer requirement|
|Surface treatment||Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.|
|Joint of Poles||Insert mode,innerflange mode,face to face joint mode|
|Design of pole||Against earthquake of 8 grade|
|Wind Speed||160 Km/Hour . 30 m /s|
|Welding||We have past flaw testing.Internal and external double welding makes the welding beautiful in shape
Welding Standard :AWS ( American Welding Society ) D 1.1
|Thickness||1 mm to 30 mm|
|Production Process||Raw material test → Cutting →Molding or bending →Weldng (longitudinal )→Dimension verify→Flange welding →Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting→Recalibration →Thread →Packages|
|Packages||Our poles as normal cover by Mat or straw bale at the top and bottom ,anyway also can following by client required , each 40HC or OT can loading how many pcs will calculation base on the client actually specification and data.|
|Established in 1991,Jiangsu Milky Way Steel Poles is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port . Our Products have been widely used in the power transmsion ,signal transmission and ligting for street ,road ,square ,palaestra.and so on.
We have plenty of export experience . Since our first overseas order from Pakstan in 1991 of 132 KV transmission poels ,our products have been deliveried to more than 70 contries and areas ,including America,Australia ,Russia ,Genmery ,Span,Philippines ,Malaysia , Dominica, Congo, Togo and Guniea so on.
1. Factory direct sale.
2. Industry and trade integration business.
3. 15 years experience.
4. Various designs.
5. ODM, OEM acceptable.
6. Flexible payment.
7. Fast, accurate quotes.
8. Our good service.
9. Technical support by e-mail.
10. Calling service.
11. Provide maintenance instruction video
