Hot Dip Galvanized Steel Philippines Metal Utility Poles For Utility Transmission Line

China Hot Dip Galvanized Steel Philippines Metal Utility Poles For Utility Transmission Line supplier
Hot Dip Galvanized Steel Philippines Metal Utility Poles For Utility Transmission Line supplier Hot Dip Galvanized Steel Philippines Metal Utility Poles For Utility Transmission Line supplier Hot Dip Galvanized Steel Philippines Metal Utility Poles For Utility Transmission Line supplier Hot Dip Galvanized Steel Philippines Metal Utility Poles For Utility Transmission Line supplier Hot Dip Galvanized Steel Philippines Metal Utility Poles For Utility Transmission Line supplier

Large Image :  Hot Dip Galvanized Steel Philippines Metal Utility Poles For Utility Transmission Line

Product Details:

Place of Origin: China
Brand Name: Milky Way
Certification: ISO, BV, SGS
Model Number: Hot Dip Galvanized Steel Utility Pole For Electrical Distribution

Payment & Shipping Terms:

Minimum Order Quantity: one 40 HQ
Price: negotiation
Packaging Details: as per customer request
Delivery Time: usually 2 weeks after confirming
Payment Terms: T/T
Supply Ability: 300 pieces pole per day
Contact Now
Detailed Product Description
Type: Straight Pole, Tensile Pole, Turn Pole Suit For: Electricity Distribution
Thickness: 1mm To 30mm Power: 10kv~550kv
Torelance Of Dimenstion: +- 2% Wind Speed: 160km/h, 30m/s





Hot Dip Galvanized Steel Philippines Metal Utility Poles For Utility Transmission Line



Specification



Height

From 9 meter to 100 meter

Suit for

Electric Power Transmission and Distribution

Shape

Polygonal or Conical

Material

Normally   Q345B/A572, Minimum Yield Strength ≥ 345 N/mm²

                  Q235B/A36, Minimum Yield Strength ≥ 235 N/mm²

As well as Hot rolled coil from ASTM A572 GR65, GR50, SS400

Power Capacity

10kV to 220kV

Tolerance of the dimension

According to client’s requirement.

Surface treatment

Hot dip galvanized Following ASTM A 123, or any other standard by client required.

Joint of Poles

Slip joint, flanged connected

Standard

ISO 9001:2008

Length of per section

Within 14 meter once forming

Welding Standard

AWS (American Welding Society ) D 1.1

Thickness

1 mm to 36mm

Production Process

Raw material test → Cutting →bending →Welding (longitudinal )→Dimension verify →Flange welding →Hole drilling →sample assemble → surface clean→ Galvanization or powder coating ,painting →Recalibration →Packages

Packages

Packing with plastic paper or according to client’s request.





Hot Dip Galvanized Steel Philippines Metal Utility Poles For Utility Transmission Line



We  produce  any dimensions and thicknesses straight round, tapered round, straight square, tapered square etc pole as your demand.

1) The main body pole adopts the technology of the disposable shaping

2) The welding seam is level and smooth
3) The welding of the lightpost is the automatic Asian arc welding
4) The antiseptic disposing of the lamp pole is the hot galvanizing and the surface is smooth and beautiful
5) Both the adjustment of the color and that of the height are alternative.
Hot Dip Galvanized Steel Philippines Metal Utility Poles For Utility Transmission Line

Terms & Conditions


1. Price Term: EXW, FOB, CFR or CIF.

The price includes pole shaft, base plate, crossarm and anchor part.

Shipping seaport: Shanghai Seaport. For FOB, CFR or CIF price, please specify which exact model you need, and tell us your order quantity so that we can calculate the local transport charges and sea freight.

2. MOQ: 1 sets.

3. Payment: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.

4. Package: Plastic paper or according to clients requirement.

5. Delivery: for 30 sets, goods can be ready for shipment within 20 workdays after receiving deposit.

6. Parts Design Service Period: 20 years.
