Polygonal Single Cross Arm Steel Galvanised Street Light Pole

Certification
China Jiangsu milky way steel poles co.,ltd certification
China Jiangsu milky way steel poles co.,ltd certification
Dear Sirs, Hereby we confirm that JiangSu MilkyWay steel poles co., ltd is our partner for several years. Since that time this company has shown itself as reliable supplier of qualitative products.We also would like to note that they provide top level service and all kinds of support.We plan to continue our fruitful cooperation co-operation for many years more.

—— Abacus

We do hereby certify the 69 KV transmmision line steel pole(from 25ft to 90 ft ) manufacuterd by Jiangsu Milky Way Steel Poles Co., Ltd since 2010.We are satisfied with their quality,service and the ways and attention they showed toward our order.

—— National Electricity Company

I'm Online Chat Now

Polygonal Single Cross Arm Steel Galvanised Street Light Pole

China Polygonal Single Cross Arm Steel Galvanised Street Light Pole supplier
Polygonal Single Cross Arm Steel Galvanised Street Light Pole supplier Polygonal Single Cross Arm Steel Galvanised Street Light Pole supplier Polygonal Single Cross Arm Steel Galvanised Street Light Pole supplier Polygonal Single Cross Arm Steel Galvanised Street Light Pole supplier

Large Image :  Polygonal Single Cross Arm Steel Galvanised Street Light Pole

Product Details:

Place of Origin: China,Jiangsu
Brand Name: MilkyWay
Certification: ISO9001/BV/SGS
Model Number: Street Light Poles

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T, L/C at sight
Supply Ability: 300pcs per day
Contact Now
Detailed Product Description
Tolerance: +/-2% Product Name: Polygonal Single Cross Arm Steel Galvanized Street Light Poles For Street
Pole Finished: Galvanized High Mast Pole Payment Terms:: T/T ,L/C
Supply Ability:: 2000pcs Per Week Safty Facor: 1.8
Brand Name: MilkyWay
High Light:

polygonal galvanised street light pole

,

single cross galvanised street light pole

,

galvanised street light pole polygonal

Polygonal single cross arm Steel galvanized Street Light Poles for street





Key Process:



(1)Material Preparation→(2)Bending→(3)Welding→(4)Repair and Grinding→(5)Reforming→(6)Flushing→(7)Fix bottom plate→(8)Welding bottom plate→(9)Opening door→(10)Welding door strip, electric strip, and locking→(11)Bending arm→(12)Hot dip galvanization→(13)Plastic powder painted→(14)Inspection→(15)Shipment



Raw material:

Polygonal Single Cross Arm Steel Galvanised Street Light Pole 0





Each process:



Material preparation



1)Before cutting the plate, first adjust the inclination to meet with required vertical shears.



2)Fix the position of steel plate, assure maximum excess material.



3)The length is decided when laying up the plate. The size of bottom should not more than ±2mm, but for high mast the tolerance should be plus, usually: 0 to 2m, for small ending, the tolerance should be minus, usually -2 to 0mm. When adjust is ready, the cutting machine will finish cutting.



4) About equipment: check condition of roller shear, clean sundries on the track, maintain good conditions.



3.Bending:



The work of bending is the most important process, which will directly influence the quality of pole, and the finished product cannot be repaired. Pay attention to following tips:



1)before bending: remove residues to keep new plate away from damage

2)check the length, width and straightness of plate, the non-straightness should be less than 1/1000, if the non-straightness meets requirement, correct, especially the polygon poles must keep non-straightness.

3)adjust the depth of bending with the bending machine, and confirm the location of plate.

4)Correctly mark line on the plate, the tolerance should be less than ±1mm.

5)Correctly line up and bend to keep min seam, meanwhile the distance between two sides should be less than 5mm.





Welding:



Weld the seams of bended plate. As it is semi-auto welding ,the welder has more work to do, he should adjust the position of welding and assure straightness of line.





Inspection:



Polygonal Single Cross Arm Steel Galvanised Street Light Pole 1
