Name: Street Lighting Single Bracket Parking Light Poles 5m Height 3mm Thickness
Brand: Jiangsu milky way steel poles co.,ltd
SKU: 5m 3mm thickness Street Light Poles with single bracket for parking lighting
Price: 545.00 USD
Availability: InStock

Street Lighting Single Bracket Parking Light Poles 5m Height 3mm Thickness

one 40 HQ

MOQ

negotiation

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Optical Assembly Of Lighting Fixture: IP 65

Suit For: Airport, Seaport, Plaza, Stadium, Square, Highway, Street Way Etc

Lamp Power: 20w-400w

Torlance Of The Dimenstion: +-2%

Wind Speed: 160km/h

Thickness: 1mm To 30mm

Highlight:

street lighting poles

street lamp pole

Basic Infomation

Place of Origin: Jiangsu, China

Brand Name: Milky Way

Certification: ISO, BV,

Model Number: 5m 3mm thickness Street Light Poles with single bracket for parking lighting

Payment & Shipping Terms

Packaging Details: as per customer request

Delivery Time: usually 2 weeks after confirming

Payment Terms: T/T

Supply Ability: 300 pieces pole per day

Gallery

Street Lighting Single Bracket Parking Light Poles 5m Height 3mm Thickness

Product Description

Technical Specification- Lighting pole sample

Length			Base Plate		Top	Bottom	Thickness	Order	Unit Price	Amount	Unit Price	Amount
					Diameter	Diameter			FOB Shanghai		fob shanghai
									USD		USD
N.	A(m)	B(m)	Side	Thickness	G(mm)	H(mm)	T(MM)	Q'ty	Hot Dip Gavanized		Powder Coating
N.	A(m)	B(m)	(mm)	(mm)	G(mm)	H(mm)	T(MM)	Q'ty	Hot Dip Gavanized		Powder Coating
1	5	0.5	300	14	60	115	3
2	6	0.7	300	14	60	126	3
3	7	0.7	300	14	60	130	4
4	8	0.7	300	14	60	140	4
5	9	0.7	300	14	60	159	4
6	10	0.7	350	16	60	170	4
7	11	0.7	350	18	60	176	4
8	12	0.5	350	18	60	180	4
9	7	0.7	300	16	76	146	4
10	8	0.7	300	16	76	156	4
11	9	0.7	350	18	76	166	4
12	10	0.7	360	18	76	176	4
13	11	0.7	360	18	76	180	4
14	12	0.7	360	18	76	196	4

Street Lighting Single Bracket Parking Light Poles 5m Height 3mm Thickness 0

Product Description

OEM&ODM
easy for installion
concise design lighting pole
high cost performance lighting pole
Material :SS400, Q235,A36 (yield strength: 235Pa 24kg/mm2 Tensile Strength: 375-460Pa 38-47kg/mm2
(Other Material is Available on Request)
·Hot Dip Galvanized (≥86um)
·Any Color Polyester Powder Coated (≥100 um)
·Taper Conical , Octagonal, Polygon Section
·With demounted bracket design,easy loaded,install,and maintenance
·Theftproof slide lock
·Category: Garden lighting,Street lighting pole, light mast,street light mast

Street Lighting Single Bracket Parking Light Poles 5m Height 3mm Thickness 1

FAQ

1. Payment: (1)Telegraphic Transfer(30% advance payment, balance before shipment

(2)Telegraphic Transfer(30% advance payment, balance against copy of documents

(3)Letter of Credit: at sight

2. Lead Time: 2 weeks after confirmed order

3. Delivery way: by sea
