8m 5KN Q345 Electric Steel Transmission Poles Galvanization 30m / S Wind Speed

China 8m 5KN Q345 Electric Steel Transmission Poles Galvanization 30m / S Wind Speed supplier
8m 5KN Q345 Electric Steel Transmission Poles Galvanization 30m / S Wind Speed supplier 8m 5KN Q345 Electric Steel Transmission Poles Galvanization 30m / S Wind Speed supplier 8m 5KN Q345 Electric Steel Transmission Poles Galvanization 30m / S Wind Speed supplier 8m 5KN Q345 Electric Steel Transmission Poles Galvanization 30m / S Wind Speed supplier

Large Image :  8m 5KN Q345 Electric Steel Transmission Poles Galvanization 30m / S Wind Speed

Product Details:

Place of Origin: China
Brand Name: Milky Way
Certification: ISO//BV
Model Number: 8m 5KN utility pole high quality Q345 electric pole Africa bid

Payment & Shipping Terms:

Minimum Order Quantity: one 40HQ
Price: negotiation
Packaging Details: as per customer request
Delivery Time: usually 2 weeks after confirming
Payment Terms: T/T
Supply Ability: 300 pieces pole per day
Detailed Product Description
Type: 8m 5KN Utility Pole High Quality Q345 Electric Pole Africa Bid Style: Galvanization
Wind Speed: 160km/h, 30m/s Torlance Of Dimenstion: +- 2%
Suit For: Electricity Distribution Welding Standard: AWS D 1.1
High Light:

electrical power poles

,

electrical transmission poles

8m 5KN utility pole high quality Q345 electric pole Africa bid



Material:

Hot rolled steel, Q235,Q345,S235, or customized

Pole’s height

8m

length

Within 16m once forming without slip joint

Wall thickness

2.5mm-20mm or optional

Pole's Shape:

Round, Polygonal, Octagonal, Conial

Arm type:

Single arm, Double arm, or as per cliens' request

Application:

road,avenue, street, expressway, park, square

Production Process

Raw material test-cutting-bending-welding-dimension verify-flange welding-hole drilling-sample assemble-surface clean-galvanization or power coating /painting-recalibration-packages

Max wind velocity

Aganist wind pressure of 160Km/h

Base plate mounted

Base plate is square, octagonal or round in shape with slotted holes for anchor bolt and dimension as per customer’s requirement.

Ground mounted

The length buried underground as per customer’s requirement.



8m 5KN Q345 Electric Steel Transmission Poles Galvanization 30m / S Wind Speed 0

Electric Power Tower includes angle steel tower, tapered tubular steel, transformer substation framework, power plant framework and so on.

A utility pole is a column or post used to support overhead power lines and various other public utilities, such as electrical cable, fiber optic cable, and related equipment such as transformers and street lights. It can be referred to as a transmission pole, telephone pole, telecommunication pole, power pole, hydro pole, telegraph pole, or telegraph post, depending on its application.



Electric power tower is the steel structure frame of bracing electrical wires, keeping a sage distance of guild wires and buildings on the ground. According to appearance, the power tower can be divided to glass type tower, cat head type tower, Shang type tower, Gan type tower and doliform tower. On the basis of application, power tower can be separated to tension type tower, linear type tower, angle type tower, transposition type tower, terminal type power tower and crossing type power tower.



The tower is mainly consists of angle steel, connecting steel plate and bolt, some is component part of steel plate welding, as column foot. The simple tower part making the hot zincification anticorrosion, transportation, construction and erection is much easy. Usually use shackles on main pole of tower which the height is less than 60 meters for convenience of workers to ascend.



8m 5KN Q345 Electric Steel Transmission Poles Galvanization 30m / S Wind Speed 1



Steel tube tower mainly use between high voltage transmission lines, with lightning rod hanging place on top, bolt connecting tower body with cross arm which has wires hanging place. The intersecting surface of tower is oblong, and the intersection surface macroaxis of tower and cross arm is 0 to 90 degree angle. In practical application, raw material can be saved of shorten the circumference of intersection surface by bearing the max bending moment of oblong intersection surface macroaxis.



8m 5KN Q345 Electric Steel Transmission Poles Galvanization 30m / S Wind Speed 2
