Monopole Power Distribution Conical Hot Dip Galvanized Steel Pole For Distribution

China Monopole Power Distribution Conical Hot Dip Galvanized Steel Pole For Distribution supplier
Monopole Power Distribution Conical Hot Dip Galvanized Steel Pole For Distribution supplier Monopole Power Distribution Conical Hot Dip Galvanized Steel Pole For Distribution supplier Monopole Power Distribution Conical Hot Dip Galvanized Steel Pole For Distribution supplier Monopole Power Distribution Conical Hot Dip Galvanized Steel Pole For Distribution supplier Monopole Power Distribution Conical Hot Dip Galvanized Steel Pole For Distribution supplier

Large Image :  Monopole Power Distribution Conical Hot Dip Galvanized Steel Pole For Distribution

Product Details:

Place of Origin: China
Brand Name: MilkyWay
Certification: ISO9001/BV/SGS
Model Number: Steel Utility Pole

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T, L/C at sight
Supply Ability: 300pcs per day
Contact Now
Detailed Product Description
Product Name: Steel Utility Pole Application: Electrical Power Transmission
Standard: ISO9001-2008 Welding Standard: AWSD 1.1
Surface Treatment: Galvanization Warranty: 15 Years



galvanized monopole power distribution conical steel utility pole for distribution





 Specifications:



series Outside Diametar Wall Thicness Plain and Tubes
mm Min. mm /SWG Kg./M Mtrs./Ton
15 L 21.3 2 0.947 1058
      M 2.6 1.21 826
      H 3.2 1.44 694
20 L 26.9 2.3 1.38 725
      M 2.6 1.56 641
      H 3.2 1.87 535
25 L 33.7 2.6 1.98 505
      M 3.2 2.41 415
      H 4 2.93 341
32 L 42.4 2.6 2.54 394
      M 3.2 3.1 323
      H 4 3.79 264
40 L 48.3 2.9 3.23 310
      M 3.2 3.56 281
      H 4 4.37 229
50 L 60.3 2.9 4.08 245
      M 3.6 5.03 199
      H 4.5 6.19 162
65 L 76.1 3.2 5.71 175
      M 3.6 6.42 156
      H 4.5 7.93 126
80 L 88.9 3.2 6.72 149
      M 4 8.36 120
      H 4.8 9.9 101
90 L 101.6 3.6 8.7 115
      M 4 9.63 144
      H 4.8 11.5 87
100 L 114.3 3.6 9.75 103
       M 4.5 12.2 82
      H 5.4 14.5 69
110 L 127 4.5 13.6 74
       M 4.8 14.5 69
      H 5.4 16.2 62
125 L 139.7 4.5 15 67
       M 4.8 15.9 63
      H 5.4 17.9 56
135 L 152.4 4.5 16.4 61
       M 4.8 17.5 57
      H 5.4 19.6 51
150 L 165.1 4.5 17.8 56
       M 4.8 18.9 52
      H 5.4 21.3 47
150 L 168.3 4.5 18.2 55
       M 4.8 19.4 52
      H1 5.4 21.7 46
      H2 6.3 25.2 40





 Description:
 The material we use is from Baosteel.According to the different strength request,we can use the  Q235,Q345 and GR65.The strength of GR 65 is best and Q235 is lowest.
 For the street light pole,we usually choose Q235 and Q345.
 The good quality of steel material guarantee the good quality of the finished steel pole.







 Welding

 Advanced submerge-arc welding and CNC welding equipment. It has past flaw testing, internal and  external double welding makes the welding beautiful in shape. It confirms with the international welding  standard of CWB and AWS D 1.1

 Monopole Power Distribution Conical Hot Dip Galvanized Steel Pole For Distribution





 Installation
 -Remove all the equipment on the pole during Assembly.
 -Circle a sling around th epole shaft of each section.
 -Fix the sling on top section to one pulley block.
 -The sling on the bottom section is tightly fixed and fixed at the center of gravity.
 -Make the steel pole vertical by tighten the sling of the top section.
 -Fix the steel pole.
 -Remove the sling.

 Monopole Power Distribution Conical Hot Dip Galvanized Steel Pole For Distribution



 Design: We have our standard pole with our design, OEM and ODM is also accpetable
 Packages: Standard seaworthy
 Delivery time: with two weeks after confirm the order.

Monopole Power Distribution Conical Hot Dip Galvanized Steel Pole For Distribution
