16m transmission line steel pole tower & Power Transmission Poles

Large Image : 16m transmission line steel pole tower & Power Transmission Poles

Product Details:

Place of Origin:	China
Brand Name:	Milky Way
Certification:	ISO//BV
Model Number:	16m

Payment & Shipping Terms:

Minimum Order Quantity:	one 40HQ
Price:	negotiation
Packaging Details:	as per customer request
Delivery Time:	usually 2 weeks after confirming
Payment Terms:	T/T
Supply Ability:	300 pieces pole per day

Contact Now

Detailed Product Description

Tolerance Of Dimension:	+- 2%	Wind Resistance:	3-500km/h
Material:	GR50 GR65 S500 S355	Height:	16m
Welding:	Welding Confirms With International Welding Standard Of CWB	Powder Coating:	Pure Polyester Powder Painting, Color Is Optional
Design:	Against 8 Grade Of Earthquake	Product Name:	16m Transmission Line Steel Pole Tower & Power Transmission Poles

Specification

Item	TIP DIAMETER	BUTT DIAMETER	THICKNESS	Pole Shape
(m)	(MM)	(MM)	(MM)	8 sides
11.8m/5KN	150	355	3
11.8m/6.5KN	180	400	3
11.8m/8KN	190	440	3
11.8m/10KN	190	450	3.5
11.8m/12.5KN	220	500	3.5
11.8m/16KN	230	560	3.5
11.8m/20KN	240	585	4
11.8m/25KN	260	655	4
11.8m/32KN	260	660	5
11.8m/40KN	260	670	6
16m/5KN	150	375	4
16m/6.5KN	180	420	4
16m/8KN	190	460	4
16m/10KN	190	510	4
16m/12.5KN	220	525	4	12 sides
16m/16KN	230	585	4
16m20KN	240	585	5
16m/25KN	260	655	5
16m/32KN	260	670	6

To assure our products qualified ,we take steps as follows :

1. Management team : We have employ the foreign export to take chaege of the overall managemnt ,especailly the technical managemnt and quality management .
2. Introducing ISO management ,We are awared ISO 9001:2008 certificate.
3. QC Inpection:It is our company policy that all the finish product should be inspected by our specialzed QC in every manufacure steps and beofore every shipment.

Material	High-quality steel Q235/SS400 from BAOSTEEL Group
Welding Technique	Automatic submerged arc welding
Surface Treatment	Hot dip galvanizing and powder painting
Welding Standard	GB11345 Grade Ⅱ
Thickness of Zinc Coating	≥ 86um
Adhesive Force of Zinc Coating	GB2694-88
Anti-wind Capacity	36.9m/s
Anti-corrosion Lifetime	≥20 years
Coating Layer	Thickness	≥100um
	Adhesive force	GB9286-880
	Hardness	≥2H
Steel Pole Height Options	3.5m~15m
Street Lighting Poles Type Options	Conical, polygonal

Company Introduction:

Jiangsu Milky Way Steel Poles which established on 1991 is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port .
Our Company has 24 years experience on producing the steel poles including the transmission power pole,street light pole,high mast pole and so on.
We exported to oversea countries since 1991 and our products have been delivered to more than 70 countries and areas ,including America,Australia ,Russia ,Germany ,Span,Philippines ,Malaysia,Africa and so on.
We are the supplier of many big project in many countries,like the street light pole of Dubai Tower.the high mast pole for Sochi Winter Olympic Game and so on.

Competitive Advantage:

1. Easy work: more than 23 years pole field. quickly understand your meaning and let you get your result.

2. Lowest MOQ: lowest quantity from 1Ton depends on different style .

3. OEM Accepted: We can produce any pole of your design.

4. Good Service: We treat clients as friends.

5. Good Quality: We have very strict quality control system .Good reputation in the market.

6. Fast & Cheap Express service: We have big discount from forwarder (Long-term Contract with TNT,DHL,UPS,FEDEX,EMS ).

7. Manufacturer Capacity : 300 pieces/day.
