6m 7m 8m Flange Type Street Light Steel Pole For Road And Highway

Large Image : 6m 7m 8m Flange Type Street Light Steel Pole For Road And Highway

Product Details:

Place of Origin:	Jiangsu
Brand Name:	milky way
Certification:	ISO 9001:2015
Model Number:	light pole

Payment & Shipping Terms:

Minimum Order Quantity:	1 container
Price:	USD 130-180/pieces
Packaging Details:	Our poles as normal cover by Mat or straw bale at the top and bottom ,anyway also can following by client required , each 40HC or OT can loading how many pics will calculation base on the client actually specification and data.
Delivery Time:	always 2 weeks
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	1000 pieces per week

Contact Now

Detailed Product Description

Material:	Yield Strength Not Less Than 235mpa	Type:	Flange Type
Height:	6m 7m 8m	Thickness:	4mm 3mm 2.75mm
Tolerance Of Dimension:	+- 2%	Optical Assembly Of Lighting Fixture:	IP 65
Working Atmosphere Of Lighting Fixture:	-35 °C~+45 °C	Wind Speed:	160 Km/Hour
High Light:	flange type street light steel pole , 8m street light steel pole , 6m street light pole for road

6m 7m 8m flange type street light steel pole for road and highway

Suit for	Airport ,seaport, plaza, stadium ,square, highway ,street way etc
Shape	Conoid ,Multi-pyramidal, Columniform , polygonal or conical
Material	Usually Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield strength>=235n/mm2 As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52-
Lamp power	20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz
Tolerance of the dimension	+- 2%
Optical assembly of lighting fixture	IP 65
Electroshock resistant protective grade	Grade Ⅰ
The casing anti-corrosion performance	Class Ⅱ
Working atmosphere of lighting fixture	-35 °C~+45 °C
Surface treatment	Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.

6m 7m 8m Flange Type Street Light Steel Pole For Road And Highway 0

Our Service:

1. Reply your inquiry in 24 working hours.

2. Experienced staffs answer all your questions in fluent English.

3. Customized design is available. UEM&UBM are welcomed.

4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.

5. Special discount and protection of sales are provided to our distributor.

6. Professional factory: We are manufacturer, specializing in producing all kinds of steel poles for more than 20 years, competitive with good quantity.

7. Sample: We can send out sample for test in one week if the order quantity is big enough. But the shipment charges is usually paid by your side, the charges will be rebounded when we have formal order.

8. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature. Welcome to contact us or visit our company.

6m 7m 8m Flange Type Street Light Steel Pole For Road And Highway 1

All of our material are purchased from famous mill factory to assure the quality

A mill certificate issued by the mill factory with stamp and signature must be provided before unload the material in our factory; otherwise we have our reason to refuse the material.

Before put into production, all the material must pass the chemical and physical analysis to make sure that they have met the requested strength and component.

Installation
-Remove all the equipment on the pole during Assembly.
-Circle a sling around th epole shaft of each section.
-Fix the sling on top section to one pulley block.
-The sling on the bottom section is tightly fixed and fixed at the center of gravity.
-Make the steel pole vertical by tighten the sling of the top section.
-Fix the steel pole.
-Remove the sling.

6m 7m 8m Flange Type Street Light Steel Pole For Road And Highway 2

Applications:

Highway Seamless Steel Pipe Park Seamless Steel Pipe
Main Roads Seamless Steel Pipe Dock Seamless Steel Pipe
Secondary Roads Seamless Steel Pipe Stadium Seamless Steel Pipe
Storage-yar Seamless Steel Pipe Overpass Seamless Steel Pipe
Industrial-Plant Seamless Steel Toll-Station Seamless Steel Pipe
