Round 5m 8m 9m Q235 Octagonal Street Light Pole

Certification
China Jiangsu milky way steel poles co.,ltd certification
China Jiangsu milky way steel poles co.,ltd certification
Dear Sirs, Hereby we confirm that JiangSu MilkyWay steel poles co., ltd is our partner for several years. Since that time this company has shown itself as reliable supplier of qualitative products.We also would like to note that they provide top level service and all kinds of support.We plan to continue our fruitful cooperation co-operation for many years more.

—— Abacus

We do hereby certify the 69 KV transmmision line steel pole(from 25ft to 90 ft ) manufacuterd by Jiangsu Milky Way Steel Poles Co., Ltd since 2010.We are satisfied with their quality,service and the ways and attention they showed toward our order.

—— National Electricity Company

I'm Online Chat Now

Round 5m 8m 9m Q235 Octagonal Street Light Pole

China Round 5m 8m 9m Q235 Octagonal Street Light Pole supplier
Round 5m 8m 9m Q235 Octagonal Street Light Pole supplier Round 5m 8m 9m Q235 Octagonal Street Light Pole supplier Round 5m 8m 9m Q235 Octagonal Street Light Pole supplier Round 5m 8m 9m Q235 Octagonal Street Light Pole supplier

Large Image :  Round 5m 8m 9m Q235 Octagonal Street Light Pole

Product Details:

Place of Origin: JIANGSU CHINA
Brand Name: milky way
Certification: ISO9001:2015
Model Number: yin-he

Payment & Shipping Terms:

Minimum Order Quantity: one container
Price: USD 99-995 PER POLE
Packaging Details: The normal package is container(Size: L*W*H). Our poles as normal cover by Mat or straw bale at the top and bottom and wood between the poles to avoide the damage on the galvanization of the pole , anyway also can following by client required , The lo
Delivery Time: 20 DAYS ALWAYS
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 POLES PER MONTH
Contact Now
Detailed Product Description
MATERIAL: Average Coating Not Less Than 345mpa LIFETIME: 50 YEARS
WELDING: AWSD1.1,penetration Rate 100% SURFACE TREATMENT: HOT DIP GALVANIZATION
SHAPE: Conoid ,Multi-pyramidal, Columniform , Polygonal Or Conical COLOR: Ral Standard
LAMP POWER: 20-400w Optical Assembly Of Lighting Fixture: IP65
High Light:

q235 octagonal street light pole

,

round 9 mtr octagonal pole

,

5m octagonal street light pole



Specification:



name

8M 9M Q235 Street Light Poles With Drawing And Specification

Type

street light pole

Shape

conical, hexagonal and octagonal

Material

Usually   Q345B/A572,minimum yield strength>=345n/mm2
Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52

Torlance of dimenstion

-0.02

Design Load in Kg

300~ 1000 Kg appliced to 50cm from the to pole

Surface treatment

Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.

Standard

Octagonal Conical tapered column
Certified by SIRIM QAS INTERNATIONAL.
Approved by JABATAN KERJA RAYA MALAYSIA.
Conforms to Standard:
Pole design : BS EN 40
Material : BS EN 10025 S275 / JIS G3101 SS400
Welding : BS 5135
Galvanizing : BS 729 / ISO 1461 ASTM A 123

Length of per section

Within 14m once forming without slip joint.

high mast pole suit for

city square,wharf,stadium

Option of high mast pole

Height from 20m to 35m
Flange mounted or planted type

Production Process of high mast pole

Raw material test  Cutting Molding or bending Welidng (longitudinal )Dimension verify Flange welding Hole drilling Calibration DeburrGalvanization or powder coating ,painting RecalibrationThread Packages









·Material :SS400, Q235,A36 (yield strength: 235Pa 24kg/mm2 Tensile Strength: 375-460Pa 38-47kg/mm2

(Other Material is Available on Request)

·Hot Dip Galvanized (≥86um)

·Any Color Polyester Powder Coated (≥100 um)

·Taper Conical , Octagonal, Polygon Section

·With demounted bracket design,easy loaded,install,and maintenance

·Theftproof slide lock

·Category: Street lighting pole, Garden Lighting pole Solar Street lighting pole, High Mast,highmast light poles,





Round 5m 8m 9m Q235 Octagonal Street Light Pole 0



1. Prices conditions

Price can be FOB, CIF ,EXW, or With taxes.


2. What will be the delivery time and what will be the mode of payment?
We have large quantities in Stock for normal color,Normal size ,for special color and products sizes it need to 3-5 days to customize.
50K units is available for most of our models in normal color and sizes
The payment can be T/T transaction,Letter of credit,Paypal,Western Union.


3. Shipment will be over sea or by air?
Generally speaking ,we ship the products by DHL UPS FEDEX express since the products isn’t too heavy for the transportation,
and oversea for led lights,and can be customized by your requirements.


4. Could you please send me the sample for the same. So that i could see and analyze its quality?
Yes. We can send samples first, samples need to be charged if the value is higher.


5. Will there be any contract for this business or trade?
Yes, there is a normal contract before the order is placed.



To assure our products qualified ,we take steps as follows :

1. Management team : We have employ the foreign export to take chaege of the overall managemnt ,especailly the technical managemnt and quality management .

2. Introducing ISO management ,We are awared ISO 9001:2008 certificate . .

3. Lofting and design software :We have transmisson power pole design software which can help us design all kinds of steel pole ,at the same time ,the TMA and LMA are adopted by us to provide the design the drawing accuratly .

4. QC Inpection:It is our company policy that all the finish product should be inspected by our specialzed QC in every manufacure steps and beofore every shipment .






Round 5m 8m 9m Q235 Octagonal Street Light Pole 1
