2.5mm 6mm Thickness NEA Street Lamp Pole ISO Certification

China 2.5mm 6mm Thickness NEA Street Lamp Pole  ISO Certification supplier
2.5mm 6mm Thickness NEA Street Lamp Pole  ISO Certification supplier 2.5mm 6mm Thickness NEA Street Lamp Pole  ISO Certification supplier 2.5mm 6mm Thickness NEA Street Lamp Pole  ISO Certification supplier 2.5mm 6mm Thickness NEA Street Lamp Pole  ISO Certification supplier

Large Image :  2.5mm 6mm Thickness NEA Street Lamp Pole ISO Certification

Product Details:

Place of Origin: Jiangsu,China
Brand Name: Milky Way
Certification: /BV/ISO9001
Model Number: Steel Utility Pole

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: As customers' request
Delivery Time: 10-30 working days after received your payment
Payment Terms: T/T, L/C at sight
Supply Ability: 30,000 Tons per month
Detailed Product Description
Type: S-500MC 11.88m-1100dan Galvanized Steel Poles Utility Pole With France Standard Shape: Round,Conical
Payment Terms: T/T,L/C Thickness: 2.5mm-16mm
Surface Finished: Hot Dip Galvanized Standard: /BV/ISO9001
High Light:

2.5mm street lamp pole

,

6mm street lamp pole

,

NEA street lamp pole

2.5mm - 6mm Thickness NEA Galvanized Steel Street Light Poles ISO Certification





Features:



 Pole’s height

All available

Type

Straight Pole ,Tensile Pole ,Turn Pole,etc

Shape of pole

Conical, Round, Polygonal---Octagonal, Dodecagonal, Hexadecagonal, etc

Crossarm

 Single or double crossarm, dimension as per customers’ requirement

Material

Steel materials conform to ASTM A36,

Q235 equivalent to SS400, S235JO. Q345 equivalent to S355JR,Grade 50

Q460 equivalent to S460, Grade 65

 Wall thickness

≥2.5mm

Once forming

13m without joint



Welding

Welding complies with CSA and AWS, AWS D1.1 standard.

The welders have got corresponding certificate after testing and inspection.

 Joint

 Joint with insert mode, flange mode.

Base plate mounted

Base plate is square or round with slotted holes for anchor bolt and dimension as per client’s requirement.

 Galvanizing

Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 orAmerican standard ASTM A123.

Voltage

 10KV~550KV

Certificates

 ISO9001-2008 , AAA credit rating, etc

Protection

Anti-corrosion and rust free – suitable for coastal area, desert, oil field and industrial area





Packing & shipping



We use sack package the poles or straw at the pole top and bottom which is our normal package. We also use wood between the poles but cost just little higher than normal package. We normally use 40HQ container and our Port limit weight for 40HQ is 26Ton.



2.5mm 6mm Thickness NEA Street Lamp Pole  ISO Certification 0





Our Company:



Estbilsed in 1991,Jiangsu Milky Way Steel Poles is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port .
Our Products have been widely used in the power transmsion ,signal transmission and ligting for street ,road ,square ,palaestra.and so on
We have plenty of export experience . Since our first overseas order from Pakstan in 1991 of 132 KV transmission poels ,our products have been deliveried to more than 70 contries and areas ,including America,Australia ,Russia ,Genmery ,Span,Philippines ,Malaysia and so on


2.5mm 6mm Thickness NEA Street Lamp Pole  ISO Certification 1

Our Servises:





1.Reply your inquiry in 24 working hours.



2. Experienced staffs answer all your questions in fluent English.



3. Customized design is available. UEM&UBM are welcomed.



4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.



5. Special discount and protection of sales are provided to our distributor.



6. Professional factory : We are manufacturer, specializing in producing all kinds of steel poles for more than 20 years, competitive with good quantity.



 7 Sample: We can send out sample for test in one week if the order quantity is big enough. But the shipment charges is usually paid by your side, the charges will be rebounded when we have formal order.



8. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature. Welcome to contact us or visit our company.
