6m 12m 20m Single Arm Street Light Poles For Road Lighting

Certification
China Jiangsu milky way steel poles co.,ltd certification
China Jiangsu milky way steel poles co.,ltd certification
Dear Sirs, Hereby we confirm that JiangSu MilkyWay steel poles co., ltd is our partner for several years. Since that time this company has shown itself as reliable supplier of qualitative products.We also would like to note that they provide top level service and all kinds of support.We plan to continue our fruitful cooperation co-operation for many years more.

—— Abacus

We do hereby certify the 69 KV transmmision line steel pole(from 25ft to 90 ft ) manufacuterd by Jiangsu Milky Way Steel Poles Co., Ltd since 2010.We are satisfied with their quality,service and the ways and attention they showed toward our order.

—— National Electricity Company

I'm Online Chat Now

6m 12m 20m Single Arm Street Light Poles For Road Lighting

China 6m 12m 20m Single Arm Street Light Poles For Road Lighting supplier
6m 12m 20m Single Arm Street Light Poles For Road Lighting supplier 6m 12m 20m Single Arm Street Light Poles For Road Lighting supplier 6m 12m 20m Single Arm Street Light Poles For Road Lighting supplier 6m 12m 20m Single Arm Street Light Poles For Road Lighting supplier

Large Image :  6m 12m 20m Single Arm Street Light Poles For Road Lighting

Product Details:

Place of Origin: JIANGSU,CHINA
Brand Name: milky way
Certification: ISO9001:2015
Model Number: 69KV

Payment & Shipping Terms:

Minimum Order Quantity: ONE CONTAINER
Price: USD 130-180POLE
Packaging Details: The normal package is container(Size: L*W*H). Our poles as normal cover by Mat or straw bale at the top and bottom and wood between the poles to avoide the damage on the galvanization of the pole , anyway also can following by client required , The lo
Delivery Time: ALWAYS 20DAYS
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000POLES/MOUTH
Detailed Product Description
MATERIAL: S355JR APPLICATION: Electricity Distribution
THICKNESS: 2.5-10MM SHAPE: POLYGON
GALVANIZATION: ASTM A123,average Coationg Not Less Than 85um WELDING: AWS D1.1,penetration 100%
LIFETIME: 50 YEARS WIND SPEED: 160KM/H
ULTIMATE TENSILE STRENGTH: 490-620MPA
High Light:

6m Street Light Poles

,

12m Street Light Poles

,

hdg metal street light pole

1. solar street light pole
2. High light transmission and efficiency
3. Solid, rustproof and durable
4. Water-proof



Straightness <0.2%
Length variation <+5nlm
Shaft body tortuosity <5°
Rod straightness <1mm
Curved arm tortuosity <2°
Curved arm across flat deviation <15°
Flange and Rod vertical deviation <1°
Flange welding position deviation <2mm
Zinc coating thickness ≥86um
Powder coating thickness ≥100um
Wind speed 36.9m/s





Power LED light source of its appearance founder special atmosphere, full of strong and generous with the king. King, leaders. King for the king's magnanimity is not only a style, but also to have the king of the quality and content. By industry experts together to build this section the intrinsic quality of new lamps reasonable, effective, perfect.

Galvanized 12m Single Arm Street Light Poles for Road Lighting 0




Product features:

1. Imported LED chip, UV and infrared, light-efficient, more stable.
2. LED packaging using high thermal conductivity of patented technologies and patented three-chamber cooling technology to effectively reduce the light resistance, the clip junction temperature can be controlled at 60 degrees below, to ensure the lamp life of over fifty thousand hours or more chips.
3. The use of ultra-high thermal conductivity aluminum radiator, corrosion-resistant surface coating superconducting hot metal paint, to ensure faster heat generated LED light source distribution.
4. Use of patented technology and specialized secondary optical lens specially designed for LED specturm and high light transmission tempered glass lamp shade, to ensure that lighting a light rate of 85% or more.
5. Wide input voltage AC drive voltage constant current, ensure that the lighting for different countries and regions, high power factor, harmonic small. Constant current driver can adjust the brightness according to different time slots.
6. Lamp appearance by the professional aesthetic design, simples, elegant, fashion.
7. Applications: highway, main roads secondary roads, alip roads and so on.
Galvanized 12m Single Arm Street Light Poles for Road Lighting 1



Structural feature:

1. Shell cast by 1800T die-casting machine, featuring high strength and compact structure.
2. Reflector is made of high purity aluminum plate extension-formed.
3. Top-lift-cover for easy repair and mainten-ance.
4. Internal bulb-replacement structure for excellent water and dust-proof property.
5. Highly-transparent toughened glass shade.


Technical parameters:

1. Protection: IP66
2. Shell's anti-corrosion property: class II
3. Working environment: -35°c~+45°c
4. Electric shock-proof rating: class I

5. Lamp holder: E40

6. Power source: 220V (±10%) / 50Hz

7. Lamp: 60W - 210W LED



Galvanized 12m Single Arm Street Light Poles for Road Lighting 2
