Galvanized Steel 12m Polygonal Street Light Poles With Single Cross Arm

Certification
China Jiangsu milky way steel poles co.,ltd certification
China Jiangsu milky way steel poles co.,ltd certification
Dear Sirs, Hereby we confirm that JiangSu MilkyWay steel poles co., ltd is our partner for several years. Since that time this company has shown itself as reliable supplier of qualitative products.We also would like to note that they provide top level service and all kinds of support.We plan to continue our fruitful cooperation co-operation for many years more.

—— Abacus

We do hereby certify the 69 KV transmmision line steel pole(from 25ft to 90 ft ) manufacuterd by Jiangsu Milky Way Steel Poles Co., Ltd since 2010.We are satisfied with their quality,service and the ways and attention they showed toward our order.

—— National Electricity Company

I'm Online Chat Now

Galvanized Steel 12m Polygonal Street Light Poles With Single Cross Arm

China Galvanized Steel 12m Polygonal Street Light Poles With Single Cross Arm supplier
Galvanized Steel 12m Polygonal Street Light Poles With Single Cross Arm supplier Galvanized Steel 12m Polygonal Street Light Poles With Single Cross Arm supplier Galvanized Steel 12m Polygonal Street Light Poles With Single Cross Arm supplier Galvanized Steel 12m Polygonal Street Light Poles With Single Cross Arm supplier

Large Image :  Galvanized Steel 12m Polygonal Street Light Poles With Single Cross Arm

Product Details:

Place of Origin: JIANGSU CHINA
Brand Name: milky way
Certification: ISO9001:2015
Model Number: yin-he

Payment & Shipping Terms:

Minimum Order Quantity: one container
Price: USD 99-995 PER POLE
Packaging Details: The normal package is container(Size: L*W*H). Our poles as normal cover by Mat or straw bale at the top and bottom and wood between the poles to avoide the damage on the galvanization of the pole , anyway also can following by client required , The lo
Delivery Time: 20 DAYS ALWAYS
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 POLES PER MONTH
Contact Now
Detailed Product Description
MATERIAL: Average Coating Not Less Than 345mpa LIFETIME: 50 YEARS
WELDING: AWSD1.1,penetration Rate 100% SURFACE TREATMENT: HOT DIP GALVANIZATION
SHAPE: Conoid ,Multi-pyramidal, Columniform , Polygonal Or Conical COLOR: Ral Standard
LAMP POWER: 20-400w Optical Assembly Of Lighting Fixture: IP65
High Light:

galvanized street light pole 12m

,

single cross arm street light poles

,

polygonal 12 meter street light pole







Each process:



Material preparation



1)Before cutting the plate, first adjust the inclination to meet with required vertical shears.



2)Fix the position of steel plate, assure maximum excess material.



3)The length is decided when laying up the plate. The size of bottom should not more than ±2mm, but for high mast the tolerance should be plus, usually: 0 to 2m, for small ending, the tolerance should be minus, usually -2 to 0mm. When adjust is ready, the cutting machine will finish cutting.



4) About equipment: check condition of roller shear, clean sundries on the track, maintain good conditions.



3.Bending:



The work of bending is the most important process, which will directly influence the quality of pole, and the finished product cannot be repaired. Pay attention to following tips:



1)before bending: remove residues to keep new plate away from damage

2)check the length, width and straightness of plate, the non-straightness should be less than 1/1000, if the non-straightness meets requirement, correct, especially the polygon poles must keep non-straightness.

3)adjust the depth of bending with the bending machine, and confirm the location of plate.

4)Correctly mark line on the plate, the tolerance should be less than ±1mm.

5)Correctly line up and bend to keep min seam, meanwhile the distance between two sides should be less than 5mm.





Welding:



Weld the seams of bended plate. As it is semi-auto welding ,the welder has more work to do, he should adjust the position of welding and assure straightness of line.





Inspection:



Galvanized Steel Street Light Poles 6m 10m Polygonal With Single Cross Arm 1
