High Performance Electrical Power Pole 45ft To 70ft Length Options

Large Image : High Performance Electrical Power Pole 45ft To 70ft Length Options

Product Details:

Place of Origin:	Jiangsu
Brand Name:	milky way
Certification:	Iso 9001:2015
Model Number:	yin-he

Payment & Shipping Terms:

Minimum Order Quantity:	1 container
Price:	USD 130-180/piece
Packaging Details:	Our poles as normal cover by Mat or straw bale at the top and bottom ,anyway also can following by client required , each 40HC or OT can loading how many pics will calculation base on the client actually specification and data.
Delivery Time:	always 2 weeks
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	1000pieces per month

Contact Now

Detailed Product Description

Height:	13m	Thickness:	1-30mm
Design:	Against 8 Grade Of Earthquake	Color:	White ,silver
Welding:	AWS D1.1	Type:	Flange Type/burial
Certification:	ISO BV	Tolerance Of Dimension:	+- 2%
High Light:	High Performance Electrical Power Pole , 70ft Electrical Power Pole , 45ft Electrical Power Pole

Specifications:

Types Length	45ft	50ft	55ft	60ft	65ft	70ft
Types Length	13.75m	15.25m	16.80m	18.30m	19.85m	21.35m
B ( 0°-2°)
Top diameter (mm)	200	200	200	200	200	200
Butt diameter (mm)	345	370	395	415	435	455
Thickness (mm)	6	6	6	6	6	6
E ( 2°-15°)
Top diameter (mm)	200	200	200	200	200	200
Butt diameter (mm)	545	585	625	660	700	740
Thickness (mm)	6	6	6	6	6	6
C ( 15°-30°)
Top diameter (mm)	250	250	250	250	250	250
Butt diameter (mm)	600	645	690	730	770	805
Thickness (mm)	6	6	6	6	6	6
D ( 30°-90°)
Top diameter (mm)	300	300	300	300	300	300
Butt diameter (mm)	680	730	725	765	755	790
Thickness (mm)	6	6	7	7	8	8
HS ( 0°-2°)
Top diameter (mm)	200	200	200	200	200	200
Butt diameter (mm)	340	360	385	400	420	440
Thickness (mm)	6	6	6	6	6	6
HT ( 2°-15°)
Top diameter (mm)	200	200	200	200	200	200
Butt diameter (mm)	485	520	550	580	615	645
Thickness (mm)	6	6	6	6	6	6
3T ( 15°-30°)
Top diameter (mm)	250	250	250	250	250	250
Butt diameter (mm)	520	540	565	595	615	640
Thickness (mm)	6	6	6	6	6	6
3D ( 30°-90°)
Top diameter (mm)	300	300	300	300	300	300
Butt diameter (mm)	585	620	650	680	715	765
Thickness (mm)	6	6	6	6	6	6

Steel

Steel Material Grade
China GB	America ASTM ASME	Japan JIS	Europen EN	Gemany DIN	England BS	International ISO
16Mn 14MnNd Q345(A.B.C.D.E)	A572MGr.50 A633MGr.C A633MGr.D	SM490A SM490B SM490C	S355JR S355JOS 355J2G3 S355J2G 4S355K2 G3 S355K2G 4S355N S355NL	St52-3	50A 50B 50C 50D 50DD	E355DD E355E Fe510B Fe510D
WH60/Q460 ( C.D.E)	A572MGr.65	SM570	S460N S460NL	StE460	55C 55E	E460C E460D
Q235 ( A.B.C.D) Q275 20 25 30 35 40 45 50 55 50Mn	A283MGr.C A283MGr.D 1020 1025 1030 1035 1040 1045 1050 1055 1053	SS400 SM400( A B) SS490 S20CS22C S25C S28C S30C S33C S35C S38C S40C S43C S45C S48C S50C S53C S55C S58C SWRH52B	S235JR S235JO S235J2G 3 1C22 1C25 1C30 1C35 1C40 1C45 1C50 1C55 2C50	St37-2 St37-3 1C22 1C25 1C30 1C35 1C40 1C45 1C50 1C55 2C50	40A 40B 40C 40D 1C22 1C25 1C30 1C35 1C40 1C45 1C50 1C55 2C50	Fe360 ( A.B.C.D) Fe430A C25E4 C30E4 C35E4 C40E4 C45E4 C50E4 C55E4 SL, SM

Single Circuit GR50 Steel Utility Pole AWS D1.1 Hot Dip Galvanized 220kV 0

Welding
We have past flaw testing. Internal and external double welding makes the welding beautiful in shape
Welding Standard :AWS ( American Welding Society ) D 1.1

Quality Control
We strictly follow the standard of ISO9001-2008. Quality is in the first place at every stage of production to ensure the
product compliance to the specification/standards. Careful inspections are carried out by highly trained inspection
engineers during every procedure from raw material stage to finished product and delivery.

Company Introduction:
Jiangsu Milky Way Steel Poles which established on 1991 is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port .
Our Company has 24 years experience on producing the steel poles including the transmission power pole,street light pole,high mast pole and so on.
We exported to oversea countries since 1991 and our products have been delivered to more than 70 countries and areas ,including America,Australia ,Russia ,Germany ,Span,Philippines ,Malaysia,Africa and so on.
We are the supplier of many big project in many countries,like the street light pole of Dubai Tower.the high mast pole for Sochi Winter Olympic Game and so on.
