Durable Octagonal Steel Power Pole with 35FT to 90FT Lengths and Protective Bitumen Finish for Transmission Lines

1 pcs
MOQ
Negotiation
Price
Durable Octagonal Steel Power Pole with 35FT to 90FT Lengths and Protective Bitumen Finish for Transmission Lines
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Steel Power Pole
Application: Power Distribution
Material: Gr65
Minimum Yield Strength: 460 Mpa
Max Ultimate Tensile Strength: 620 Mpa
Wall Thickness: 1mm-36mm
Highlight:

Octagonal Steel Power Pole

,

35FT to 90FT Transmission Line Pole

,

Protective Bitumen Finish Galvanized Steel Pole
Basic Infomation
Place of Origin: China
Brand Name: MilkyWay
Certification: ISO9001/BV/
Model Number: Steel Power Pole
Payment & Shipping Terms
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T,L/C at sight
Supply Ability: 300pcs per day
Product Description
Durable Steel Power Pole Specifications
Octagonal galvanized transmission line poles ranging from 35FT to 90FT lengths with protective bitumen finish, designed for reliable power distribution infrastructure.
Types Length 45ft (13.75m) 50ft (15.25m) 55ft (16.80m) 60ft (18.30m) 65ft (19.85m) 70ft (21.35m)
B (0°-2°) Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 345 370 395 415 435 455
Thickness (mm) 6 6 6 6 6 6
E (2°-15°) Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 545 585 625 660 700 740
Thickness (mm) 6 6 6 6 6 6
C (15°-30°) Top diameter (mm) 250 250 250 250 250 250
Butt diameter (mm) 600 645 690 730 770 805
Thickness (mm) 6 6 6 6 6 6
D (30°-90°) Top diameter (mm) 300 300 300 300 300 300
Butt diameter (mm) 680 730 725 765 755 790
Thickness (mm) 6 6 7 7 8 8
HS (0°-2°) Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 340 360 385 400 420 440
Thickness (mm) 6 6 6 6 6 6
HT (2°-15°) Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 485 520 550 580 615 645
Thickness (mm) 6 6 6 6 6 6
3T (15°-30°) Top diameter (mm) 250 250 250 250 250 250
Butt diameter (mm) 520 540 565 595 615 640
Thickness (mm) 6 6 6 6 6 6
3D (30°-90°) Top diameter (mm) 300 300 300 300 300 300
Butt diameter (mm) 585 620 650 680 715 765
Thickness (mm) 6 6 6 6 6 6
Material Description
  • Poles are manufactured by high-quality metal plants, molded into multi-row cone-shaped vertical steel bars with hot galvanized anti-corrosion treatment
  • Light plate frame is constructed from high-quality stainless steel
  • Fastened bolts and nuts are made of durable stainless steel
Durable Octagonal Steel Power Pole with 35FT to 90FT Lengths and Protective Bitumen Finish for Transmission Lines 0
Our Service Commitment
  • Response to inquiries within 24 working hours
  • Experienced staff providing comprehensive answers in fluent English
  • Customized design available with UEM & UBM welcome
  • Exclusive solutions provided by professional engineers and staff
  • Special discounts and sales protection for distributors
  • Professional manufacturing with over 20 years of steel pole production experience
  • Sample availability for testing with shipment charges typically paid by customer and rebounded upon formal order
  • Superior raw materials, advanced machinery, and skilled technicians ensuring high quality and stable features
Durable Octagonal Steel Power Pole with 35FT to 90FT Lengths and Protective Bitumen Finish for Transmission Lines 1
Company Introduction
Jiangsu Milky Way Steel Poles, established in 1991, is located in Wuxi, East China, near Shanghai Port. With over 24 years of experience in producing steel poles including transmission power poles, street light poles, and high mast poles, we have exported to more than 70 countries worldwide including America, Australia, Russia, Germany, Spain, Philippines, Malaysia, and Africa.
We are proud suppliers for major international projects including street light poles for Dubai Tower and high mast poles for the Sochi Winter Olympic Games.
