15m Galvanized Steel Electric Pole Column Power Line Iso Approval

ONE CONTAINER
MOQ
USD 130-180POLE
Price
15m Galvanized Steel Electric Pole Column Power Line Iso Approval
Features Gallery Product Description Request A Quote
Features
Specifications
MATERIAL: S355JR
APPLICATION: ELECTRICITY DISTRIBUTION
THICKNESS: 2.5-10MM
SHAPE: POLYGON
GALVANIZATION: ASTM A123,average Coationg Not Less Than 85um
WELDING: AWS D1.1,penetration 100%
LIFETIME: 50 YEARS
WIND SPEED: 160KM/H
ULTIMATE TENSILE STRENGTH: 490-620MPA
Highlight:

15m steel electric pole

,

column galvanized steel electric pole

,

iso steel electric pole
Basic Infomation
Place of Origin: JIANGSU,CHINA
Brand Name: milky way
Certification: ISO9001:2015
Model Number: 69KV
Payment & Shipping Terms
Packaging Details: The normal package is container(Size: L*W*H). Our poles as normal cover by Mat or straw bale at the top and bottom and wood between the poles to avoide the damage on the galvanization of the pole , anyway also can following by client required , The lo
Delivery Time: ALWAYS 20DAYS
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000POLES/MOUTH
Product Description

Specifications

1. small floor area & large bearing load
2. reasonable distribution of load carrying capability
3. steel electric pole



Product information



Steel tower type Tubular steel pole
Voltage 220kV and below
Material Q235,Q345,Q420
Welding CO2 protection welding or submerged arc auto methods
Shape Generally round/polygonal face, and can be designed as the customers require.
Surface laye Zink layer with hot dip galvanized
Lifetime More than 50 years
Production capacity: 30000MT per year







Production Line



The fabrication process as cutting plate, bending/forming, automatic welding, drill holes, quality check before galvanized, hot dip galvanized , recalibration, inspect according to client’s required then delivery on time as Constract.





Material



Applied to the material of general-purpose steel GB/T1591-2008, ASTM A36, ASTM A572.

Q235 used in China , which equivalent to SS400, ASTM A36.

Q345 used in China, which equivalent to S355JR. Gr 50. Min Yield Stress 345 Mpa.

Q460 used in China , which Gr65.



Design and Detail



Lofting and design software :We have transmisson power pole design software which can help us design all kinds of steel pole ,at the same time ,the TMA and LMA are adopted by us to provide the design the drawing accuratly



15m Galvanized Steel Electric Pole Column Power Line Iso Approval 0



Company Information

Established in 1991,Jiangsu Milky Way Steel Poles is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port .

Our Products have been widely used in the power transmsion ,signal transmission and ligting for street ,road ,square ,palaestra.and so on.

We have plenty of export experience . Since our first overseas order from Pakstan in 1991 of 132 KV transmission poels ,our products have been deliveried to more than 70 contries and areas ,including America,Australia ,Russia ,Genmery ,Span,Philippines ,Malaysia , Dominica, Congo, Togo and Guniea so on.


FAQ



1. Price Term: EXW, FOB, CFR or CIF.

The price includes pole shaft, base plate, cross arm and anchor part.

Shipping seaport: Shanghai Seaport. For FOB, CFR or CIF price, please specify which exact model you need, and tell us your order quantity so that we can calculate the local transport charges and sea freight.

2. MOQ: 1 sets for Customized

3. Payment: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.

4. Delivery time : goods can be ready for shipment within 10 workdays after receiving deposit.

5 Warranty : 30 years

6.Surface treatment :hot dip galvanization
