30mm Electric Utility Power Pole 550kv Power Line Transmission Poles

one 40 HQ
MOQ
negotiation
Price
30mm Electric Utility Power Pole 550kv Power Line Transmission Poles
Features Gallery Product Description Request A Quote
Features
Specifications
Power: 10kv~550kv
Type: Straight Pole, Tensile Pole, Turn Pole
Thickness: 1mm To 30mm
Wind Speed: 160km/h, 30m/s
Tolerance: +/-2%
Design Load In Kg: 300~ 1000 Kg Applicated To 50cm From The To Pole
Highlight:

30mm Electric Utility Power Pole

,

Electric Utility Power Pole

,

550kv Power Line Transmission Poles
Basic Infomation
Place of Origin: China
Brand Name: Milky Way
Certification: /BV/ISO
Model Number: Electric power pole utility power pole power transmission poles power line
Payment & Shipping Terms
Packaging Details: as per customer request
Delivery Time: usually 2 weeks after confirming
Payment Terms: T/T
Supply Ability: 300 pieces pole per day
Product Description

Electric power pole utility power pole power transmission poles power line





Specification



Material:

 Q345, Gr65, S500

Shape of pole:

Round,conical,octagonal,square,mid hinged,polygonal shafts are made of steel sheet that folded into required shape and welded longitudinally by automaticarc welding machine



Groung mounted:

The length buried underground as per customers requirement



Galvanizing:



Hot dip galvanization, average thickness not less than 86um



Powder coating:

Pure polyester powder painting, color is optional





30mm Electric Utility Power Pole 550kv Power Line Transmission Poles 0



Production Process



Our factory own advance production line, machine including bending calibration machine, hydraulic plate shears machine, shears machine, slitting machine, 208T hydraulic straightener, etc. All the purpose is to produce good quality steel poles.



The fabrication process as cut plate, bending, forming, automatic welding, drill holes, quality check before galvanized, hot dip galvanized and powder coating, finally quality check according by client’s required.



30mm Electric Utility Power Pole 550kv Power Line Transmission Poles 1
