6m 7m 8m flange type street light steel pole for road and highway
| Suit for |
Airport ,seaport, plaza, stadium ,square, highway ,street way etc |
| Shape |
Conoid ,Multi-pyramidal, Columniform , polygonal or conical
|
| Material |
Usually Q345B/A572,minimum yield strength>=345n/mm2
Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52-
|
| Lamp power |
20 W- 400 W (HPS/MH)
220V (+-10%) /50Hz
|
| Tolerance of the dimension |
+- 2% |
| Optical assembly of lighting fixture |
IP 65 |
| Electroshock resistant protective grade |
Grade Ⅰ |
| The casing anti-corrosion performance |
Class Ⅱ |
| Working atmosphere of lighting fixture |
-35 °C~+45 °C |
| Surface treatment |
Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
|
Our Service:
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. Customized design is available. UEM&UBM are welcomed.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
5. Special discount and protection of sales are provided to our distributor.
6. Professional factory: We are manufacturer, specializing in producing all kinds of steel poles for more than 20 years, competitive with good quantity.
7. Sample: We can send out sample for test in one week if the order quantity is big enough. But the shipment charges is usually paid by your side, the charges will be rebounded when we have formal order.
8. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature. Welcome to contact us or visit our company.
All of our material are purchased from famous mill factory to assure the quality
A mill certificate issued by the mill factory with stamp and signature must be provided before unload the material in our factory; otherwise we have our reason to refuse the material.
Before put into production, all the material must pass the chemical and physical analysis to make sure that they have met the requested strength and component.
Installation
-Remove all the equipment on the pole during Assembly.
-Circle a sling around th epole shaft of each section.
-Fix the sling on top section to one pulley block.
-The sling on the bottom section is tightly fixed and fixed at the center of gravity.
-Make the steel pole vertical by tighten the sling of the top section.
-Fix the steel pole.
-Remove the sling.
Applications:
Highway Seamless Steel Pipe Park Seamless Steel Pipe
Main Roads Seamless Steel Pipe Dock Seamless Steel Pipe
Secondary Roads Seamless Steel Pipe Stadium Seamless Steel Pipe
Storage-yar Seamless Steel Pipe Overpass Seamless Steel Pipe
Industrial-Plant Seamless Steel Toll-Station Seamless Steel Pipe
