14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance

200
MOQ
$1
Price
14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance
Features Gallery Product Description Request A Quote
Features
Specifications
Material: 14M 500 Dan Electricity Transmission Steel
Mounting Height: 14m
Shape: Round Conical; Octagonal Conical; Straight Square; Tubular Stepped; Polygonal
Brackets: Single Or Double Brackets As Per Customer Requirement
Welding Standard: AWS D 1.1
Base Plate: Square Or Round With Slotted Holes
Ground Mounted Length: As Per Customer Requirement
Galvanizing Thickness: 80-100µm Average
Powder Coating: Pure Polyester Powder Painting
Wind Resistance: 3-500km/h
Thickness Range: 1 Mm To 30 Mm
Shaft Construction: Steel Sheet Folded And Longitudinally Welded
Welding Process: Internal And External Double Welding
Galvanization Standard: IS2629-1985, BS729-1971
Packing Weight: 26T
Highlight:

14m Height Transmission Steel Pole

,

ISO9001/BV/SGS Certified Electric Power Pole

,

Wind Resistance 3-500km/h Steel Utility Pole
Basic Infomation
Place of Origin: Jiangsu, China
Brand Name: Milky Way
Model Number: Electrical Power Ple
Payment & Shipping Terms
Product Description
Galvanized Steel Electric Pole Transmission Monopole
Product Specifications
Material 14M 500 Dan Electricity Transmission Steel Utility Pole for Power Distribution Line Project
Mounting Height 14m
Shape of Pole Round conical; Octagonal conical; Straight square; Tubular stepped; Polygonal
Brackets Single or double brackets available in custom shapes and dimensions
Welding Complies with international welding standard CWB and AWS D1.1
Base Plate Square or round with slotted holes for anchor bolts (custom dimensions available)
Ground Mounting Buried length customized per requirements
Galvanizing Hot dip galvanization (80-100µm average thickness)
Powder Coating Pure polyester powder painting (color optional)
Wind Resistance 3-500 km/h
Thickness 1 mm to 30 mm
14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 0
Production Process
14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 1
Raw Material Processing

All raw materials (steel plates) include mill certificates and undergo elongation tests and chemical composition analysis before production to ensure compliance with required standards.

Cutting Process

Materials are precision-cut using CNC laser cutting technology, which delivers high-quality surface finishes through controlled melting and vaporization of material.

14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 2 14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 3
Molding & Welding

Steel plates are formed into specified shapes (circular, polygonal, etc.) using advanced bending machines. Longitudinal welding is performed with AC inverter control for stable, high-quality seams.

14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 4 14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 5
Galvanization

All poles receive hot-dip galvanization (IS2629-1985, BS729-1971 standards) for superior corrosion resistance.

Certifications
14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 6
Company Profile
14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 7

Established in 1991, Jiangsu Milky Way Steel Poles Co., Ltd. is located in Wuxi, China, near Shanghai Port. Our products serve power transmission, signal transmission, and lighting applications worldwide.

With over 20 years of manufacturing experience, we've exported to more than 70 countries and maintain BV, ISO, and SGS certifications.

Packing & Delivery
14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 8
Packing Size 40HQ
Weight 26T
Packaging Details Poles are packed with sea/road-worthy wooden materials. Loading capacity per container varies based on specifications.
Frequently Asked Questions
How can I get a price for a needed pole?

Provide exact dimensions (height, thickness, material, diameters) or send a drawing for accurate pricing.

Do you accept small orders?

Yes, we welcome small wholesalers and are happy to grow with our customers.

Can you produce custom-designed samples?

We specialize in helping customers realize their designs and solve technical challenges.

How does your Door to Door service work?

We handle all shipping and customs clearance, offering time and cost savings through our shipping partnerships.
