6m 12m 20m Single Arm Street Light Poles For Road Lighting
6m 12m 20m Single Arm Street Light Poles For Road Lighting
Basic Properties
Place of Origin:
JIANGSU,CHINA
Brand Name:
milky way
Certification:
ISO9001:2015
Model Number:
69KV
Trading Properties
Minimum Order Quantity:
ONE CONTAINER
Price:
USD 130-180POLE
Payment Terms:
L/C, T/T, Western Union
Supply Ability:
1000POLES/MOUTH
Product Summary
1. solar street light pole 2. High light transmission and efficiency 3. Solid, rustproof and durable 4. Water-proof Straightness
Product Custom Attributes
Highlight
6m Street Light Poles
,12m Street Light Poles
,hdg metal street light pole
MATERIAL:
S355JR
APPLICATION:
Electricity Distribution
THICKNESS:
2.5-10MM
SHAPE:
POLYGON
GALVANIZATION:
ASTM A123,average Coationg Not Less Than 85um
WELDING:
AWS D1.1,penetration 100%
LIFETIME:
50 YEARS
WIND SPEED:
160KM/H
ULTIMATE TENSILE STRENGTH:
490-620MPA
Product Description
Detailed Specifications & Features
1. solar street light pole
2. High light transmission and efficiency
3. Solid, rustproof and durable
4. Water-proof
| Straightness | <0.2% |
| Length variation | <+5nlm |
| Shaft body tortuosity | <5° |
| Rod straightness | <1mm |
| Curved arm tortuosity | <2° |
| Curved arm across flat deviation | <15° |
| Flange and Rod vertical deviation | <1° |
| Flange welding position deviation | <2mm |
| Zinc coating thickness | ≥86um |
| Powder coating thickness | ≥100um |
| Wind speed | 36.9m/s |
Power LED light source of its appearance founder special atmosphere, full of strong and generous with the king. King, leaders. King for the king's magnanimity is not only a style, but also to have the king of the quality and content. By industry experts together to build this section the intrinsic quality of new lamps reasonable, effective, perfect.
Product features:
1. Imported LED chip, UV and infrared, light-efficient, more stable.
2. LED packaging using high thermal conductivity of patented technologies and patented three-chamber cooling technology to effectively reduce the light resistance, the clip junction temperature can be controlled at 60 degrees below, to ensure the lamp life of over fifty thousand hours or more chips.
3. The use of ultra-high thermal conductivity aluminum radiator, corrosion-resistant surface coating superconducting hot metal paint, to ensure faster heat generated LED light source distribution.
4. Use of patented technology and specialized secondary optical lens specially designed for LED specturm and high light transmission tempered glass lamp shade, to ensure that lighting a light rate of 85% or more.
5. Wide input voltage AC drive voltage constant current, ensure that the lighting for different countries and regions, high power factor, harmonic small. Constant current driver can adjust the brightness according to different time slots.
6. Lamp appearance by the professional aesthetic design, simples, elegant, fashion.
7. Applications: highway, main roads secondary roads, alip roads and so on.
Structural feature:
1. Shell cast by 1800T die-casting machine, featuring high strength and compact structure.
2. Reflector is made of high purity aluminum plate extension-formed.
3. Top-lift-cover for easy repair and mainten-ance.
4. Internal bulb-replacement structure for excellent water and dust-proof property.
5. Highly-transparent toughened glass shade.
Technical parameters:
1. Protection: IP66
2. Shell's anti-corrosion property: class II
3. Working environment: -35°c~+45°c
4. Electric shock-proof rating: class I
5. Lamp holder: E40
6. Power source: 220V (±10%) / 50Hz
7. Lamp: 60W - 210W LED
