Galvanized Painting Conical Electrical Power Pole Iso Standard

 High Voltage Galvanized Conical Electric Power Distribution Transmission Line Towers

 Specification:

 The followed design is based on ASTMA 572 Gr 65 material,with octagonal cross section shape,while the  safety factor is 1.8.If you have other requirement on load,height,material and cross section shape,pls  contact us.

  Description:
 Standard Accessory
 - Top plate
 - Base plate
 - Bottom strip
 - Standard hole
 - Climbing rung
 - Anchor bolt
 - Bitumen protection
 - Painted marking
 - Removable ladder
 These are the standard accessories of the electric pole.

 Steel
 The material is in accordance with NF EN 10025
 Standard and NF EN 10149 Standard,it has the following property.
 - Yield Strength=355N/mm2
 - Toughness remains the same under 20 degrees below zero.
 - Galvanization is in accordance with NFA35503 Standard Class 1.

 Galvanization
 Standard:NFA91121
 Average thickness of the galvanization:Not less than 86μm.

 Manufacture Tolerance
 - Component Length:-25mm to 75mm
 - Straightness:2mm/m
 - Twisting degree:1°per 3 meters length
 - Ovalisation:Maximum is 3%
 - The average diameter:+/-0.5%
 - Slip length:+/-150mm

 Company Introduction:

 JiangSu Milky Way Steel Poles Co., Ltd.was established in 1988, is located in Yixing City, Jiangsu  Province, Wan Shi Town, covering an area of 35,000 square meters, annual output value reached 200  million . We have 20 years experience in design and  production. Our main products are power pole,  communication towers, street lighting poles, steel bracket and so on. The company has strong technical  force, advanced production equipment, perfect quality management system, product quality has reached  international advanced level.
