Home /Products/Steel Power Pole/40feet One Section Antirust Steel Utility Pole

40feet One Section Antirust Steel Utility Pole

500pieces
MOQ
USD 1-500/poles
Price
40feet One Section Antirust Steel Utility Pole
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Q235 Q345 GR65 SS400
Wind Speed: 35m/s
Origin Of Place: Yixing
Type: Burial
Surface Treament: Hot Dip Galvanization
Galvanization Standard: ASTM A123
Welding: AWS D1.1
Warrenty: 30 Years
Lifetime: 50 Years
Highlight:

40feet steel utility pole

,

one section steel utility pole

,

antirust steel power pole
Basic Infomation
Place of Origin: Jiangsu
Brand Name: milky way
Certification: ISO9001:2015
Model Number: steel pole
Payment & Shipping Terms
Packaging Details: Our poles as normal cover by Mat or straw bale at the top and bottom ,anyway also can following by client required , each 40HC or OT can loading how many pics will calculation base on the client actually specification and data.
Delivery Time: always 2 weeks
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000per month
Product Description
Material: Hot rolled steel, Q235,Q345,S235,S355,SS400,Gr 50
Yield strength of Material:

Minimum yield strength>=235n/mm2 for Q235, S235 and SS400

Minimum yield strength>=345n/mm2 for Q345 S355 and Gr 50
Pole’s height: 3m –15m
Length of one part Within 16m once forming without slip joint
Wall thickness: 2.3mm-30mm
Pole's Shape Can be made:

Round, Polygonal, Taper Octagonal, Taper round,

Round conical, Taper Square, Square.
Arm type can be made: Single arm, Double arm, Tri-arm, Four-arm
Arm Diameter:

Diameter as 42mm, 48mm, 60mm, 76mm and etc,

can fit to any diameter’s lamps.
Power: 250W to 400W
Welding

Advanced submerge-arc welding and CNC welding equipment. It has past flaw

testing,

internal and external double welding makes the welding

beautiful in shape. It confirms with the international welding

standard of CWB and AWS D 1.1
Galvanization:

Hot dip galvanization with thickness of 80-100µm average

in accordance with Chinese standardGB/T 13912-2002

or American standard ASTM A123, ISO: 2626-1985.
Manufactury Capacity Per Day: 250

Wall thickness Tolerance:



+- 0.1mm from 2.3mm to 4mm.

+- 0.2mm from 5mm to 20mm. +- 0.5mm from 22mm to 30mm
Painting color: (RAL)Color card or Refer to client’s requirement
Surface treatment 1: Black pole, Rough pole
Surface treatment 2: Hot dip Galvanizing antirust.
Surface treatment 3: Hot dip galvanizing with powder coating
Temperature range -35 °C~+45 °C
Wind Speed:

Aganist wind pressure of 120Km/h to 180Km/h,

it according to client’s design.
Base plate mounted

Base plate is square, octagonal or round

in shape with slotted holes for anchor bolt and dimension

as per customer’s requirement.
Ground mounted: The length buried underground as per customer’s requirement.
Quality Control According to ISO9001-2008 requirements.
Certificates ISO9001-2008, Audited Supplier, The AAA grade certificate of goodwill
Other Less land occupation & easy maintenance.



40feet One Section Antirust Steel Utility Pole 0
Production Flow:
The production process:Row material test → Cutting →Molding or bending →Welding (longitudinal )→Dimension verify →Flange welding→Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting →Recalibration →Thread →Packages

40feet One Section Antirust Steel Utility Pole 1



The information to inquiry or purchase
- Steel pole height
- Dimension of the flange
- Position and dimension of the service door
- Cross arm type and length,the position to install in the steel pole
- The method to fix the cross arm(use bolt to connect or use one or two template to weld in the steel pole to install the cross arm)
- Wind speed
- Destination port
- Other.





40feet One Section Antirust Steel Utility Pole 2
