Home /Products/Power Transmission Poles/Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV

Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV

1 pcs
MOQ
Negotiation
Price
Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Galvanized Power Pole
Shape: Octagonal Or Round
Power Capacity: 10kV To 220kV
Joint Of Poles: Slip Joint
Warranty Time: 15 Years
Thickness: 1 Mm To 36mm
Highlight:

galvanized steel power transmission poles

,

25ft-40ft power transmission poles

,

10kV-220kV power transmission poles
Basic Infomation
Place of Origin: China
Brand Name: MilkyWay
Certification: ISO9001/BV/
Model Number: Transmission Steel Power Pole
Payment & Shipping Terms
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T,L/C at sight
Supply Ability: 300pcs per day
Product Description
Galvanized Steel Power Transmission Poles for Utility Lines
Available in 25ft, 30ft, 35ft, and 40ft lengths with competitive pricing
Product Specifications
Product Name Galvanized Power Pole
Shape Octagonal Or Round
Power Capacity 10kV to 220kV
Joint of Poles Slip joint
Warranty time 15 years
Thickness 1 mm to 36mm
Steel Material Quality
All materials are sourced from reputable mills to ensure quality. Each shipment includes a mill certificate with stamp and signature for verification before unloading.
Before production, all materials undergo rigorous chemical and physical analysis to confirm they meet required strength and composition standards.
Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 0
Detailed Specifications
Types Length 45ft 50ft 55ft 60ft 65ft 70ft
13.75m 15.25m 16.80m 18.30m 19.85m 21.35m
B (0°-2°)
Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 345 370 395 415 435 455
Thickness (mm) 6 6 6 6 6 6
Manufacturing Tolerances
  • Component Length: -25mm to 75mm
  • Straightness: 2mm/m
  • Twisting degree: 1° per 3 meters length
  • Ovalisation: Maximum is 3%
  • The average diameter: +/-0.5%
  • Slip length: +/-150mm
Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 1
Welding Standards
Our welding processes have passed flaw testing. We use internal and external double welding for both strength and aesthetic quality.
Welding Standard: AWS (American Welding Society) D 1.1
Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 2
Surface Treatment
Hot dip galvanized following ASTM A 123 standards. Custom color polyester powder or other client-required finishes available.
Company Introduction
Jiangsu Milky Way Steel Poles, established in 1991 and located in Wuxi, China near Shanghai Port, has over 24 years of experience manufacturing steel poles including transmission power poles, street light poles, and high mast poles.
Since 1991, we've exported to over 70 countries worldwide including the USA, Australia, Russia, Germany, Spain, Philippines, Malaysia, and throughout Africa.
We've supplied major projects globally, including street light poles for Dubai Tower and high mast poles for the Sochi Winter Olympic Games.
Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 3
