Home /Products/Utility Power Poles/15m Galvanized Octagonal Steel Utility Pole 2.75mm Thickness

15m Galvanized Octagonal Steel Utility Pole 2.75mm Thickness

1 pcs
MOQ
Negotiation
Price
15m Galvanized Octagonal Steel Utility Pole 2.75mm Thickness
Features Gallery Product Description Request A Quote
Features
Specifications
Height: 14.5m
Pole Shape: Octagonal
Thickness: 2.75mm
Welding Standard: AWS D 1.1
Surface Treatment: Galvanization Bitumen
Dimenstion Torlance: +- 2%
Highlight:

15m galvanized steel utility pole

,

octagonal utility power pole

,

2.75mm thick steel pole
Basic Infomation
Place of Origin: China
Brand Name: MilkyWay
Certification: ISO9001/BV/
Model Number: Steel Utility Pole
Payment & Shipping Terms
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T,L/C at sight
Supply Ability: 300pcs per day
Product Description
15m Tapered Steel Utility Power Poles
2.75mm thickness with 850kg load capacity. Available in multiple configurations: 11M 13.5KN, 12.5M 12KN, 12.5M 16KN, 12.5M 24KN.
Product Specifications
Attribute Value
Height 14.5m
Pole Shape Octagonal
Thickness 2.75mm
Welding Standard AWS D 1.1
Surface treatment Galvanization bitumen
Dimension tolerance ±2%
Technical Specifications
Product Code Length ULS Pole Dimension (Top/Base)
11M 13.5KN 11M 13.5kN 160/328
12.5M 12KN 12.5M 12KN 160/340
12.5M 16KN 12.5M 16KN 180/380
12.5M 24KN 12.5M 24KN 200/420
14M 16KN 14M 16KN 190/402
14M 24KN 14M 24KN 210/465
Pole Design
15m Galvanized Octagonal Steel Utility Pole 2.75mm Thickness 0
Standard Accessories
  • Top plate
  • Base plate
  • Bottom strip
  • Standard hole
  • Climbing rung
  • Anchor bolt
  • Bitumen protection
  • Painted marking
  • Removable ladder
Available Foundation Types
  • Direct Embedment
  • Anchor Bolt/Base Plate
  • Vibratory Steel Caisson
Available Finishes
  • Galvanized per ASTM A123
  • Paint over galvanized
  • Paint over black steel
  • Powder Coating
Standard Features
In-Ground Mounted:
  • 12-sided pole shaft
  • Welded top cap
  • Mounting holes (to your specification if required)
  • Identification plate
  • M12 earth point 250mm above the nominal ground line
  • M24 nut 250mm above the nominal ground line (to assist lifting)
  • Additional in-ground corrosion protection 200mm above to 400mm below the nominal ground line
  • Anti-sink straps
  • Hot dip galvanised finish
Base Plate Mounted:
  • 12-sided pole shaft (40kN to 80kN)
  • 16-sided pole shaft (100kN & 120kN)
  • Welded top cap
  • Mounting holes (to your specification if required)
  • Identification plate
  • M12 earth point 250mm above the pole base
  • Two lifting gussets on the base plate
  • Anchor bolts, templates, nuts & washers
  • Hot dip galvanised finish
Product Dimension
15m Galvanized Octagonal Steel Utility Pole 2.75mm Thickness 1
Utility poles support wires and components for electric power, telecommunications, cable television, and fiber optic services. Transmission lines carry electric power from source to substations, where distribution lines branch off to supply surrounding areas. Transmission structures are distinguished by taller poles, larger rights-of-way (75-200 feet), and higher voltages (typically 69 kV or above).
Company Introduction
Jiangsu Milky Way Steel Poles, established in 1991 and located in Wuxi, China near Shanghai Port, has 24 years of experience producing steel poles including transmission power poles, street light poles, and high mast poles. Since 1991, we've exported to over 70 countries including the USA, Australia, Russia, Germany, Spain, Philippines, Malaysia, and Africa. Our products have been used in major projects worldwide, including the street light poles for Dubai Tower and high mast poles for the Sochi Winter Olympic Games.
