220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line

10
MOQ
$99
Price
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line
Features Gallery Product Description Request A Quote
Features
Specifications
Rated Current: 220KV
Rated Voltage: 10kv-138kv
Mounting Height: 14m
Shape: Round Conical; Octagonal Conical; Straight Square; Tubular Stepped; Polygonal
Welding Standard: AWS D.1.1
Galvanizing Thickness: 80-100µm Average
Powder Coating: Pure Polyester Powder Painting
Wind Resistance: 3-500km/h
Material Thickness: 1 Mm To 30 Mm
Base Plate: Square Or Round With Slotted Holes
Ground Mount Length: As Per Customer Requirement
Brackets: Single Or Double As Per Customer Requirement
Material: 14M 500 Dan Electricity Transmission Steel
Welding Type: Internal And External Double Welding
Production Process: CNC Laser Cutting, Automatic Arc Welding
Highlight:

220KV Rated Electrical Power Pole

,

10kv-138kv Rated Transmission Line Pole

,

AWS D.1.1 Welding Standard Steel Power Pole
Basic Infomation
Place of Origin: Jiangsu, China
Brand Name: Milky Way
Model Number: Electrical Power Ple
Payment & Shipping Terms
Product Description
Electric Pole Specifications
General Specifications
Feature Description
Material 14M 500 Dan Electricity Transmission Steel Utility Pole For Power Distribution Line Project
Mounting Height 14m
Shape of Pole Round conical; Octagonal conical; Straight square; Tubular stepped; Polygonal
Brackets Single or double brackets as per customer requirements
Welding Conforms with international welding standard of CWB
Base Plate Square or round with slotted holes for anchor bolts
Ground Mounting Buried length as per customer requirements
Galvanizing Hot dip galvanization (80-100µm average thickness)
Powder Coating Pure polyester powder painting (color optional)
Wind Resistance 3-500km/h
Welding Standard AWS (American Welding Society) D 1.1
Thickness 1 mm to 30 mm
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 0
Production Process
Raw Material
Steel plates are purchased with mill certificates. Quality department performs elongation tests and chemical composition analysis to ensure materials meet required standards before production.
Cutting
Materials are cut to required dimensions using CNC laser cutting technology, ensuring high-quality surface finish on all edges.
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 1 220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 2
Molding
Cut steel plates are formed into required shapes (circular, polygonal, etc.) using specialized bending machines.
Welding
Plates are welded longitudinally using A.C. inverter controlled welding machines with seam-tracking arc-guide mechanism for precision alignment.
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 3 220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 4
Galvanization
All poles are hot-dip galvanized internally and externally according to IS2629-1985 and BS729-1971 standards.
Certifications
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 5
Company Profile
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 6
Jiangsu Milky Way Steel Poles Co.,Ltd.
Established in 1991 and located in Wuxi, near Shanghai port. Our products are used in power transmission, signal transmission, and lighting applications worldwide.
With over 20 years of experience, we've exported to more than 70 countries including USA, Australia, Russia, Germany, Spain, Philippines, and Malaysia. We are BV, ISO, and SGS certified.
Packing & Delivery
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 7
Packing Specification Details
Size 40HQ
Weight 26T
Packaging Details Poles are packed with sea/road-worthy wooden materials. Loading capacity per container varies based on client specifications.
Frequently Asked Questions
How can I get a price for needed pole?
1. Provide exact dimensions (height, thickness, material, diameters) for a quote.
2. Send drawings for precise pricing.
Do you accept small orders?
Yes, we welcome small wholesalers and are happy to grow with our customers.
Can you produce custom designed samples?
Yes, we welcome opportunities to help bring custom designs to reality.
How to apply to be your agent?
Send your proposal and company profile to delia@yin-he.com.
Do you offer door-to-door delivery service?
Yes, we provide complete door-to-door service including customs clearance, with discounted shipping rates.
