Home /Products/Steel Power Pole/Gr65 Material Steel Power Pole with 460 MPa Yield Strength and 620 MPa Tensile Strength for High Voltage Transmission

Gr65 Material Steel Power Pole with 460 MPa Yield Strength and 620 MPa Tensile Strength for High Voltage Transmission

1 pcs
MOQ
Negotiation
Price
Gr65 Material Steel Power Pole with 460 MPa Yield Strength and 620 MPa Tensile Strength for High Voltage Transmission
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Steel Power Pole
Application: Power Distribution
Material: Gr65
Minimum Yield Strength: 460 Mpa
Max Ultimate Tensile Strength: 620 Mpa
Wall Thickness: 1mm-36mm
Highlight:

Gr65 Material Steel Power Pole

,

460 MPa Yield Strength Electric Transmission Pole

,

620 MPa Tensile Strength Galvanized Steel Pole
Basic Infomation
Place of Origin: China
Brand Name: MilkyWay
Certification: ISO9001/BV/
Model Number: Steel Power Pole
Payment & Shipping Terms
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T,L/C at sight
Supply Ability: 300pcs per day
Product Description
35FT 70FT 90FT Bitumen Coated Steel Power Pole for High Voltage Power Transmission Line
Product Specifications
Types Length 45ft (13.75m) 50ft (15.25m) 55ft (16.80m) 60ft (18.30m) 65ft (19.85m) 70ft (21.35m)
B (0°-2°)
Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 345 370 395 415 435 455
Thickness (mm) 6 6 6 6 6 6
E (2°-15°)
Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 545 585 625 660 700 740
Thickness (mm) 6 6 6 6 6 6
C (15°-30°)
Top diameter (mm) 250 250 250 250 250 250
Butt diameter (mm) 600 645 690 730 770 805
Thickness (mm) 6 6 6 6 6 6
D (30°-90°)
Top diameter (mm) 300 300 300 300 300 300
Butt diameter (mm) 680 730 725 765 755 790
Thickness (mm) 6 6 7 7 8 8
Material Description
  • Poles are made by high-quality metal plants, molded into multi-row cone-shaped vertical steel bars with hot galvanized anti-corrosion treatment
  • Light plate frame is made of high-quality stainless steel
  • Fastened with stainless steel bolts and nuts
Gr65 Material Steel Power Pole with 460 MPa Yield Strength and 620 MPa Tensile Strength for High Voltage Transmission 0
Our Services
1. Reply to your inquiry within 24 working hours
2. Experienced staff answer all questions in fluent English
3. Customized designs available (UEM&UBM welcomed)
4. Exclusive solutions provided by professional engineers
5. Special discounts and sales protection for distributors
6. Professional manufacturer with 20+ years experience in steel pole production
7. Samples available for testing (shipping charges may apply)
8. Superior raw materials and advanced manufacturing processes ensure high quality
Gr65 Material Steel Power Pole with 460 MPa Yield Strength and 620 MPa Tensile Strength for High Voltage Transmission 1
Company Introduction
Jiangsu Milky Way Steel Poles, established in 1991 and located in Wuxi, China near Shanghai Port, specializes in manufacturing steel poles including transmission power poles, street light poles, and high mast poles.
With 24 years of experience, we have exported to over 70 countries including America, Australia, Russia, Germany, Spain, Philippines, Malaysia, and Africa.
Notable projects include supplying street light poles for Dubai Tower and high mast poles for the Sochi Winter Olympic Games.
