Customizable Street Light Poles with Lengths up to 14 Meters Without Slip Joint and Multiple Flange Mounted or Planted Type Options
Customizable Street Light Poles with Lengths up to 14 Meters Without Slip Joint and Multiple Flange Mounted or Planted Type Options
Basic Properties
Place of Origin:
China
Brand Name:
Milky Way
Certification:
ISO//BV
Model Number:
14m
Trading Properties
Minimum Order Quantity:
one 40HQ
Price:
negotiation
Payment Terms:
T/T
Supply Ability:
300 pieces pole per day
Product Summary
Product Description 9m 10m 12m Q235 Hot Dip Galvanized Street Lamp Pole With Cross Arm Specification: Specification: 20-50 meters street light pole Type street light pole Shape conical, hexagonal and octagonal Material Usually Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield ...
Product Custom Attributes
Highlight
customizable street light poles
,street light poles without slip joint
,flange mounted street light poles
Tolerance Of Dimension:
+- 2%
Wind Resistance:
3-500km/h
Material:
GR50 GR65 S500 S355
Height:
14m
Welding:
Welding Confirms With International Welding Standard Of CWB
Powder Coating:
Pure Polyester Powder Painting, Color Is Optional
Design:
Against 8 Grade Of Earthquake
Product Name:
Customizable Street Light Poles With Lengths Up To 14 Meters Without Slip Joint And Multiple Flange Mounted Or Planted Type Options
Product Description
Detailed Specifications & Features
Product Description
9m 10m 12m Q235 Hot Dip Galvanized Street Lamp Pole With Cross Arm
Specification:
| Specification: | 20-50 meters street light pole |
| Type | street light pole |
| Shape | conical, hexagonal and octagonal |
| Material | Usually Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield strength>=235n/mm2 As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52 |
| Torlance of dimenstion | -0.02 |
| Design Load in Kg | 300~ 1000 Kg appliced to 50cm from the to pole |
| Surface treatment | Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required. |
| Standard | Octagonal Conical tapered column Certified by SIRIM QAS INTERNATIONAL. Approved by JABATAN KERJA RAYA MALAYSIA. Conforms to Standard: Pole design : BS EN 40 Material : BS EN 10025 S275 / JIS G3101 SS400 Welding : BS 5135 Galvanizing : BS 729 / ISO 1461 ASTM A 123 |
| Length of per section | Within 14m once forming without slip joint. |
| high mast pole suit for | city square,wharf,stadium |
| Option of high mast pole | Height from 20m to 35m Flange mounted or planted type |
| Production Process of high mast pole | Raw material test → Cutting →Molding or bending →Welidng (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration →Deburr→Galvanization or powder coating ,painting →Recalibration→Thread →Packages |
·Material :SS400, Q235,A36 (yield strength: 235Pa 24kg/mm2 Tensile Strength: 375-460Pa 38-47kg/mm2
(Other Material is Available on Request)
·Hot Dip Galvanized (≥86um)
·Any Color Polyester Powder Coated (≥100 um)
·Taper Conical , Octagonal, Polygon Section
·With demounted bracket design,easy loaded,install,and maintenance
·Theftproof slide lock
·Category: Street lighting pole, Garden Lighting pole Solar Street lighting pole, High Mast,highmast light poles,
