Outdoor 6M Double Arm Painting Galvanized Steel Pole Q234 Material for Road Lighting
galvanised steel poles
,power line pole
Outdoor 6M Double Arm Painting Steel Pole Q234 Material for Road Lighting
Specifications:
|
Suit for |
Airport ,seaport,plaza,stadium ,square,highway, |
|
Shape |
Conoid ,Multi-pyramidal,Columniform,polygonal or conical |
|
Surface treatment |
Hot dip galvanized Following ASTM A 123, |
|
Joint of Poles |
Insert mode,innerflange mode,face to face joint mode |
|
Design of pole |
Against earthquake of 8 grade |
|
Wind Speed |
160 Km/Hour |
|
Minimum yield strength |
355 mpa |
|
Minimum ultimate tensile strength |
490 mpa |
|
Max ultimate tensile strength |
620 mpa |
|
Standard |
ISO 9001 |
|
Length of per section |
Within 14m once forming without slip joint |
1.Height :4 m~15 m
2.Max length per section :14 m
3.Thickness :2.5mm~30 mm
4.Shape:Conical or polygongal tapered
5.Material : Q235B/A36/A283 M Gr.C /SS400/S235 JR/St 37-2 /Fe 360
6.Lamp Power :9 W~800 W (HPS/MH)
7.Finish :hot dipgalvanization ,blasting,powder coating ,painting
8.Galvanization standard :ASTMA 123 / EN ISO 1461
9.Welding:AWS D 1.1 /BS EN 1011-1,BS EN 1011-2
Design:We have our standard pole with our design,OEM and ODM is also accpetable
Packages :Standard seaworthy
Delivery time :with two weeks after confirm the order
Galvanization
Standard:NFA91121
Average thickness of the galvanization:Not less than 70μm.
Manufacture Tolerance
-Component Length:-25mm to 75mm
-Straightness:2mm/m
-Twisting degree:1°per 3 meters length
-Ovalisation:Maximum is 3%
-The average diameter:+/-0.5%
-Slip length:+/-150mm
