Galvanized Steel Power Pole with Octagonal Shape and Bitumen Coating Available in 35FT to 90FT Lengths
Galvanized Steel Power Pole with Octagonal Shape and Bitumen Coating Available in 35FT to 90FT Lengths
Basic Properties
Place of Origin:
China
Brand Name:
MilkyWay
Certification:
ISO9001/BV/
Model Number:
Steel Power Pole
Trading Properties
Minimum Order Quantity:
1 pcs
Price:
Negotiation
Payment Terms:
T/T,L/C at sight
Supply Ability:
300pcs per day
Product Summary
Galvanized Steel Power Pole - Octagonal Transmission Line Poles High-quality galvanized steel power poles featuring octagonal shape design with bitumen coating, available in various lengths from 35FT to 90FT for transmission line applications. Product Specifications Types Length 45ft (13.75m) 50ft ...
Product Custom Attributes
Highlight
Octagonal Shape Steel Power Pole
,Bitumen Coating Transmission Line Pole
,35FT to 90FT Lengths Galvanized Steel Pole
Product Name:
Steel Power Pole
Application:
Power Distribution
Material:
Gr65
Minimum Yield Strength:
460 Mpa
Max Ultimate Tensile Strength:
620 Mpa
Wall Thickness:
1mm-36mm
Product Description
Detailed Specifications & Features
Galvanized Steel Power Pole - Octagonal Transmission Line Poles
High-quality galvanized steel power poles featuring octagonal shape design with bitumen coating, available in various lengths from 35FT to 90FT for transmission line applications.
Product Specifications
| Types Length | 45ft (13.75m) | 50ft (15.25m) | 55ft (16.80m) | 60ft (18.30m) | 65ft (19.85m) | 70ft (21.35m) |
|---|---|---|---|---|---|---|
| B (0°-2°) | ||||||
| Top diameter (mm) | 200 | 200 | 200 | 200 | 200 | 200 |
| Butt diameter (mm) | 345 | 370 | 395 | 415 | 435 | 455 |
| Thickness (mm) | 6 | 6 | 6 | 6 | 6 | 6 |
| E (2°-15°) | ||||||
| Top diameter (mm) | 200 | 200 | 200 | 200 | 200 | 200 |
| Butt diameter (mm) | 545 | 585 | 625 | 660 | 700 | 740 |
| Thickness (mm) | 6 | 6 | 6 | 6 | 6 | 6 |
| C (15°-30°) | ||||||
| Top diameter (mm) | 250 | 250 | 250 | 250 | 250 | 250 |
| Butt diameter (mm) | 600 | 645 | 690 | 730 | 770 | 805 |
| Thickness (mm) | 6 | 6 | 6 | 6 | 6 | 6 |
| D (30°-90°) | ||||||
| Top diameter (mm) | 300 | 300 | 300 | 300 | 300 | 300 |
| Butt diameter (mm) | 680 | 730 | 725 | 765 | 755 | 790 |
| Thickness (mm) | 6 | 6 | 7 | 7 | 8 | 8 |
Material Description
- Poles manufactured by high-quality metal plants, molded into multi-row cone-shaped vertical steel bars with hot galvanized anti-corrosion treatment
- Light plate frame constructed from high-quality stainless steel
- Fastened bolts and nuts made of durable stainless steel
Our Service Commitment
Reply to your inquiry within 24 working hours
Experienced staff answering all questions in fluent English
Customized design available with UEM & UBM welcome
Exclusive solutions provided by professional engineers
Special discounts and sales protection for distributors
Professional manufacturing with over 20 years of experience
Sample availability for testing with formal order rebates
Superior raw materials and advanced manufacturing processes
Company Introduction
Jiangsu Milky Way Steel Poles, established in 1991 and located in Wuxi, East China near Shanghai Port, brings over 24 years of expertise in producing steel poles including transmission power poles, street light poles, and high mast poles.
Since 1991, our products have been exported to more than 70 countries worldwide including America, Australia, Russia, Germany, Spain, Philippines, Malaysia, Africa and others. We are proud suppliers for major international projects including street light poles for Dubai Tower and high mast poles for the Sochi Winter Olympic Games.
