Home /Products/Galvanized Steel Pole/Gr65 Galvanized Steel Transmission Pole ASTM A123 Gr65

Gr65 Galvanized Steel Transmission Pole ASTM A123 Gr65

one 40 HQ
MOQ
negotiation
Price
Gr65 Galvanized Steel Transmission Pole ASTM A123 Gr65
Features Gallery Product Description Request A Quote
Features
Specifications
Shape: Conoid, Multi-pyramidal, Columniform, Polygonal Or Conical
Welding Standard: AWS D1.1
Tolerance: +/-2%
Design Load In Kg: 300~ 1000 Kg Applicated To 50cm From The To Pole
Material: Steel, Q235, Q345, Gr65, S500
Highlight:

Galvanized steel transmission pole

,

Gr65 Galvanized steel transmission pole

,

ASTM A123 Galvanized transmission pole
Basic Infomation
Place of Origin: China
Brand Name: Milky Way
Certification: BV/ISO
Model Number: Galvanized steel pole tapered steel pole metal telephone pole ASTM A123
Payment & Shipping Terms
Packaging Details: as per customer request
Delivery Time: usually 2 weeks after confirming
Payment Terms: T/T
Supply Ability: 300 pieces pole per day
Product Description



Galvanized steel pole steel transmission pole steel pipe galvanized ASTM A123



Surface

Hot dip galvanizing
Warranty 1 year for steel pole, and 15 years for galvanization

Temperature range

-35 °C~+45 °C

Max wind velocity

Aganist wind pressure of 160Km/h

Base plate mounted

Base plate is square, octagonal or round in shape with slotted holes for anchor bolt and dimension as per customer’s requirement.

Ground mounted

The length buried underground as per customer’s requirement.

Quality Control

We are well equipped with superior production equipments, solid technical strength, excellent managing mode and quality control system, perfect after service. We have passed the ISO9001:2008 Quality Systems Authentication.

Certificates

ISO9001-2008,  Audited Supplier, The AAA grade certificate of goodwill

Other

Less land occupation & easy maintenance





Gr65 Galvanized Steel Transmission Pole ASTM A123 Gr65 0





Welding
After molding, weld the steel plate together. Usually it is longitudinal welds. It adopts A.C.inverter control, with functions of stable running and fast traveling speed; The seam-tracking arc-guide mechanism is three-spindle system to guarantee the alignment without aberrancy; The main frame and welding machine are intergrated control, with flux auto-recovering system and it is easy to operate with high efficiency.


Gr65 Galvanized Steel Transmission Pole ASTM A123 Gr65 1


Galvanization
All poles internally and externally are to be hot-dip galvanized in accordance with requirement mentioned in the relevant drawing or specification Galvanization standard:IS2629-1985 ,BS729-1971


Gr65 Galvanized Steel Transmission Pole ASTM A123 Gr65 2









Company Information



Established in 1991,Jiangsu Milky Way Steel Poles is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port .

Our Products have been widely used in the power transmsion ,signal transmission and ligting for street ,road ,square ,palaestra.and so on.



We have plenty of export experience . Since our first overseas order from Pakstan in 1991 of 132 KV transmission poels ,our products have been deliveried to more than 70 contries and areas ,including America,Australia ,Russia ,Genmery ,Span,Philippines ,Malaysia , Dominica, Congo, Togo and Guniea so on.



Gr65 Galvanized Steel Transmission Pole ASTM A123 Gr65 3
