Astm 25ft 30ft 35ft Steel Galvanized Pole Yield Strength 345mpa 3mm

Large Image : Astm 25ft 30ft 35ft Steel Galvanized Pole Yield Strength 345mpa 3mm

Product Details:

Place of Origin:	China
Brand Name:	MilkyWay
Certification:	ISO9001/BV/
Model Number:	Galvanized Steel Pole

Payment & Shipping Terms:

Minimum Order Quantity:	1 pcs
Price:	Negotiation
Packaging Details:	As customer request
Delivery Time:	20 working days after received your payment
Payment Terms:	T/T, L/C at sight
Supply Ability:	300pcs per day

Contact Now

Detailed Product Description

Product Name:	Galvanized Steel Pole	Galvanization Standard:	ASTM A 123
Material:	Q235	Life Time:	50 Years
Wind Speed:	30m/s	Warranty:	15 Years
Dimenstion Torlance:	+- 2%
High Light:	astm steel galvanized pole , 30ft steel galvanized pole , 3mm 25 foot galvanized pole

25FT 30FT 35FT Yield Strength 345Mpa 3mm Galvanized Steel Metal Power Poles

Description:

Our Transmission Pole is designed for the high voltage power transmission and low voltage power transmission.
Designed and manufacutred for durability, corrosion resistance and visual appeal.

Specifications:

Shape	Conoid ,Multi-pyramidal,Columniform,polygonal or conical
Optical assembly of lighting fixture	IP 65
Electroshock resistant protective grade	Grade Ⅰ
The casing anti-corrosion performance	Class Ⅱ
Working atmosphere of lighting fixture	-35 ℃~+45 ℃
Joint of Poles	Insert mode,innerflange mode,face to face joint mode
Design of pole	Against earthquake of 8 grade
Wind Speed	160 Km/Hour
Minimum yield strength	355 mpa
Minimum ultimate tensile strength	490 mpa
Max ultimate tensile strength	620 mpa
Standard	ISO 9001
Length of per section	Within 14m once forming without slip joint
Style	Size and styles are veriable as per customer request

Material:

The material we use is from Baosteel.According to the different strength request,we can use the Q235,Q345 and GR65.The strength of GR 65 is best and Q235 is lowest.
For the street light pole,we usually choose Q235 and Q345.
The good quality of steel material guarantee the good quality of the finished steel pole.

The material is in accordance with NF EN 10025
Standard and NF EN 10149 Standard,it has the following property.
-Yield Strength=355N/mm2
-Toughness remains the same under 20 degrees below zero.
-Galvanization is in accordance with NFA35503 Standard Class 1.
